1 Introduction
1.2 Environmentally-friendly disposal of materials and components
6 Service Manual SIPLACE MeasurementFeeder X 02/2020
1.2 Environmentally-friendly disposal of materials and
components
Our products are manufactured using only materials and parts that can be easily separated and
disposed of in an environmentally-friendly way.
NOTICE
Observe the applicable regulations
The company operating the system has sole responsibility for the proper, environmentally-
friendly disposal of machines, working materials, consumable materials and wear parts.
► Please observe your national statutory provisions for waste disposal and environ-
mental protection.
1.3 Use of original accessories and spare parts
Only use original spare parts and authorized accessories. The use of other parts will affect safety
and will invalidate the liability for any consequential damage.
1.4 Requirements
To correctly repair MeasurementFeeder modules, you require an ESD-compatible workplace with a
stable, level and clean surface.
Required tools
●
SIPLACE X Feeder Verification System (FVS), item no. 03126186-xx
●
SIPLACE MeasurementFeeder X Calib. Kit, item no.03220703-01
●
Flat-bladed screwdriver 0.9 Nm
●
Phillips screwdriver 0.9 Nm
●
TORX screwdriver 0.6Nm, size T8
●
Sliding foil remover [03075421-xx]
1.5 Information About This Service Manual
WARNING
Additional qualifications required
The service work described in this manual may only be performed by specially trained per-
sonnel and therefore requires additional qualifications and skills.
Please contact your SIPLACE service team if you have any special questions about service work.
1 Introduction
1.6 SIPLACE on the World Wide Web (WWW)
Service Manual SIPLACE MeasurementFeeder X 02/2020 7
1.6 SIPLACE on the World Wide Web (WWW)
Log in to our SIPLACE® homepage at http://www.asm-smt.com.
You can choose between the German and English version.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can also access the MySIPLACE user group. Here you can call
up special information about our placement systems, e.g.
●
technical documentation
●
technical information
●
spare parts lists etc.
Registration for the MySIPLACE user group is very simple:
► At the head of the web site, click on and then on the Register
link.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with user name and password.
1 Introduction
1.6 SIPLACE on the World Wide Web (WWW)
8 Service Manual SIPLACE MeasurementFeeder X 02/2020
