1] Servo Control Table – X, Y & Theta axis and Table Z1 & Z2 2] Servo Control Squeegee Y axis with Precise Ball screw 3] Servo Control Camera X & Y axis 4] Automatic Width adjustment 3 stages conveyors 5] Eas…
Leading Edge & Advanced Technology
Hardware Feature - Strong. Stable. Useful
1] Servo Control Table – X, Y & Theta axis and Table Z1 & Z2
2] Servo Control Squeegee Y axis with Precise Ball screw
3] Servo Control Camera X & Y axis
4] Automatic Width adjustment 3 stages conveyors
5] Easy to change Mask stencil with Plunger
6] Wet, Dry, Vacuum Cleaning with Solvent Tank (4 liter)
7] Industrial PC with UPS
8] High stiffness frame
Basic Structure
ES-E & H Table
4 Ball screws with High precision, High stiffness and
additional 3 shafts
Servo Control for Table axis – X, Y and Theta – and Z1 & Z2
Equal printing pressure break up to guarantee high
accurate printing quality and long run use without a trouble
PATENT for Theta Axis precise adjustment
ESE printer table structure can break up a printing pressure
equally unlike other printers.
This mechanism can guarantee the machine table durability
and can save Table calibration cost for long using.
Table each axis (X.Y.Theta) accuracy can be measured
anytime from embedded program
