With Easy to use Plunger for Mask stencil change Depends on printer model, 550mm ~ 1800mm Mask frame can be loaded Mask frame thickness 20mm ~ 40mm can be loaded and Max 45mm thickness frame can be loaded ES-E & H St…
For customer self-diagnose,
Camera Auto calibration program for a focusing applied
Camera X and Y axis driven & controlled by ball screw and Servo
Camera recognizes a mark on PCB and Stencil simultaneously
Camera 4 LED lights applied for much perfect 2D inspection and recognition as per
mark color, PCB color etc
Field of View 11mm x 8mm
The smallest Mark size is 0.1mm
ES-E & H Vision Camera –Auto calibration
With Easy to use Plunger for Mask stencil change
Depends on printer model, 550mm ~ 1800mm Mask frame can be loaded
Mask frame thickness 20mm ~ 40mm can be loaded and Max 45mm thickness
frame can be loaded
ES-E & H Stencil –Auto loading & positioning
Standard Stencil Auto loading, Unloading and Positioning function applied
Dual vacuum applied for much perfect cleaning
Standard Wet. Dry. Vacuum cleaning mode
Advanced-design, no-clog stencil-cleaning system with
programmable paper-saving features
Cleaning speed and Cleaning mode (direction, repeat, group etc)
can be programmable
ES-E & H Cleaning
Easy & fast detachable cleaning Vacuum Metal Bar
Innovative new technologic Cleaning
system
AHORRO (Hybrid) cleaning system
Paper 40% saving
Paperless cleaning mode available for
paper changing
Easy & fast detachable kit system
