Automatic Solder Dispenser _ JAR type Automatic Solder Dispenser for JAR Type solder paste bottle 1] 500g Solder paste bottle [ Normal bottle can be used as it is after removing Cap ] 2] Dispenser can be modified depends…
Optional Items to improve productivity
Auto solder paste
dispenser
(JAR, Tube)
Glue Dispenser
Solder paste
height check
Temperature &
Humidity Display
Air conditioner
Temperature
controller
Barcode
management
(scanner + SW)
Touch screen
monitor
Auto support pin
placement
Auto side lifter
system
Side vacuum
clamp kit
Customizing
vacuum nest
Real Squeegee
pressure closed
loop
Y (side) clamp
pressure control
Area safety sensor
Center vacuum
monitor sensor
3D printing
solution
RFID managing
Ionizer cleaning
for PCB
Mask stencil
detect sensor
Easy
clip(one-touch)
squeegee
Paperless
cleaning
Enclosed print
head squeegee
To improve your productivity,
ESE has been supplying a retrofit optional items
Please consult any optional items if needed
Automatic Solder Dispenser _ JAR type
Automatic Solder Dispenser for
JAR Type solder paste bottle
1] 500g Solder paste bottle
[ Normal bottle can be used as it is after removing Cap ]
2] Dispenser can be modified depends on a bottle size
3] Dispenser move left to right
4 With only Outlet change, Simple cleaning and Cleaning
finishing better than existing other dispenser
5] No Solder tailing
OPTION
Automatic Solder Dispenser for
Tube Type solder paste bottle
1] 500g Solder paste
2] With rotary cylinder, it can be rotated by 90 degree
3] Compared with JAR Type, Solder consumption is better (5%)
4] Solder quantity can be adjustable
Glue Dispenser
OPTION
Glue Dispenser
1] Discharging time : 0.05~99.99s
2] Control : Electro Pneumatic
3] Barrel : 5cc
4] Available Nozzle ( Inner Diameter _ mm) :
0.18, 0.21, 0.25, 0.26, 0.29, 0.34, 0.42, 0.52.
0.61, 0.72, 0.92, 1.11, 1.25, 1.43, 1.64, 1.64, 2.27
5. Available Fluid : UV Bond, Tuffy, Grease oil, lubricative liquid
Glue Dispenser
1] Discharging time : 0.05~99.99s
2] Control : Electro Pneumatic
3] Barrel : 5cc
4] Available Nozzle ( Inner Diameter _ mm) :
0.18, 0.21, 0.25, 0.26, 0.29, 0.34, 0.42, 0.52.
0.61, 0.72, 0.92, 1.11, 1.25, 1.43, 1.64, 1.64, 2.27
5. Available Fluid : UV Bond, Tuffy, Grease oil, lubricative liquid
Solder paste Dispenser
ESE will update for this option
