Back-to-Back and High- speed Printer H1 and H2 ES-H1 ES-H2 PCB size 50mm x 50mm - 350mm x 250mm [ * Optional 380mm x 280mm ] 50mm x 50mm - 550mm x 400mm PCB Thickness 0.3mm to 6mm 0.3mm to 6mm Stencil size 550mm, 584m…
Economic & Smart and Flexible Printer
E2. E2+. E7
ES-E2 and E2+ ES-E7
PCB size 50mm x 50mm - 550mm x 510mm 70mm x 70mm - 700mm x 610mm
PCB Thickness 0.3mm to 6mm 0.3mm to 6mm
Stencil size 550mm, 584mm, 650mm, 736mm 650mm, 736mm, 800mm, 850mm, 900mm
Cycle time 10sec / under optimized condition 12sec / under optimized condition
Alignment accuracy ±12.5 um @ 6 sigma ±12.5 um @ 6 sigma
Printing repeatability
±25 um @ 6 sigma , Cpk ≥2.0
E2+ : ±20 um @ 6 sigma , Cpk ≥2.0
±25 um @ 6 sigma , Cpk ≥2.0
The model E2 from US-2000X & 2000XQ is designed for a high
performance of quality and a scaled-up capacity
ESE best cost-effective model with much more enhanced standard
features integrated
Much stable solid frame & Table structure for a cost-saving and 3 stages
conveyor system for high throughput
The model E7 from US-7000X is designed for a flexible printing
capacity of PCB 700mm by 610mm
based on E2’s stable printing repeatability
With enhanced standard features integrated on E2, standard
3 stages conveyor system for high throughput
E2. E2+. E7
Back-to-Back and High- speed Printer
H1 and H2
ES-H1 ES-H2
PCB size
50mm x 50mm - 350mm x 250mm
[ * Optional 380mm x 280mm ]
50mm x 50mm - 550mm x 400mm
PCB Thickness 0.3mm to 6mm 0.3mm to 6mm
Stencil size 550mm, 584mm (23”), 650mm 550mm, 584mm (23”), 650mm, 736mm(29”)
Core Cycle time 5sec / under optimized condition 6sec / under optimized condition
Alignment accuracy ±12.5 um @ 6 sigma ±10 um @ 6 sigma
Printing repeatability ±25 um @ 6 sigma , Cpk ≥2.0 ±20 um @ 6 sigma , Cpk ≥2.0
H1 Ultimate cycle time [ core 5sec ] and Qualified printing
quality & repeatability printer [ 20um@6sigma ] for single or
back-to-back configurable printer
Much high productivity for single products – Top & Bottom
printing together on each lane
Linear motor applied for stable & fast camera and 3 stages
conveyor system as standard
H2 realizes super cycle time based on ESE own technology
[ core cycle time – 5.5~6 sec and including cleaning – 10sec under ESE
optimized condition ]
The most stable mechanical structure and printing performance with
machine alignment 10microns and repeatability 20microncs will make you
cut down sharply your production time and much higher productivity
Linear motor applied for stable & fast camera and 3 stages conveyor system
as standard
H1. H2
Professional Large Printer
E8. US-LX
E8. LX
The automatic stencil printing system E8 based on Standard E2 & E7 platform was developed to cover LED, LCD and
much larger substrate up to 850mm.
As a qualified professional large printer by a leading LED, LCD customers, E8 includes all standard E2 & E7 printer features
& function and most flexible system in this industry field.
Up to 10kgs* substrate weight on E8 can be handled and flexible design allows customer mask stencil size loading
including ESE standard configuration (Optional)
Including Standard clamping system, special designed side vacuum clamp tool kit supports much perfect board
clamping and printing result from a warpage
All LX printer - an effective X direction printing & cleaning applied
ES-E8 US-LX1 US-LX3 US-LX5
PCB size 70mm x 70mm - 850mm x 610mm 100mm x 80mm - 1000mm x 650mm 100mm x 80mm - 1300mm x 650mm 100mm x 80mm - 1500mm x 650mm
PCB Thickness 0.3mm to 6mm 0.3mm to 6mm 0.3mm to 6mm 0.3mm to 6mm
Stencil size
736mm(29”), 800mm, 850mm, 980mm,
1050mm x 850mm
736mm(29”), 980mm, 1300mm x 800mm
736mm(29”), 980mm,
1500mm x 800mm
736mm(29”), 980mm,
1800mm x 800mm
Cycle time 17sec 35sec / 1000mm PCB 40sec / 1000mm PCB 45sec / 1000mm PCB
Alignment accuracy ±12.5 um @ 6 sigma ±12.5 um @ 3 sigma ±12.5 um @ 3 sigma ±12.5 um @ 3 sigma
Printing repeatability ±25 um @ 6 sigma ±25 um @ 3 sigma , Cpk ≥1.33 ±25 um @ 3 sigma , Cpk ≥1.33 ±25 um @ 3 sigma , Cpk ≥1.33
