Touch Screen Monitor Barcode Management ( Scanner + SW ) OPTION Touch screen Monitor All program menu touch With Barcode managing system, Customer can manage each production materials _ Stencil, Solder, Squeegee ETC . Al…
Auto Side lifter system
Automatic Support Pin Placement
OPTION
Automatic Pin Placement is to precisely place and remove
pins.
Pin location can be designated by User with Gerber file.
Pin positions are software programmable ensures quick, easy
and repeatable product changeover
For much perfect PCB edge support and a magnetic support
plate or pin can not support PCB edge,
Auto side lifer (2 blades) system can be applied
Touch Screen Monitor
Barcode Management ( Scanner + SW )
OPTION
Touch screen Monitor
All program menu touch
With Barcode managing system, Customer can manage each production materials _
Stencil, Solder, Squeegee ETC.
All data can be saved on FDC file
Real squeegee pressure closed Loop
Side (Y) clamp pressure control
OPTION
Real time squeegee (Front & Rear) pressure closed loop system
Digital indicator located to inside Squeegee head cover
Printing area pressure tolerance +/-1kgf/sec (+/-38um/sec)
Real squeegee pressure closed loop [ Load cell ]
: This optional function is to verify if the actual squeegee pressure for actual printing at printing
starting point is same with the programmed squeegee pressure. This is to confirm that a
printing pressure is same as like the setting pressure.
Real time squeegee pressure closed loop [ Load cell ]
: This optional function is to control actual printing pressure during whole printing.
Y ( Side ) Clamp pressure can be programmable and can be saved per
each product model
