MODEL PXH-1 1006-004 159 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE K-7 641 6300699616 ACCESSOR Y ,P .C.B 8 831K--1 10-641 23L10045 642 6301401249 BRACKET 1 831K--1 10-642 21 1F A122 650 6301387550 UNIT ,I…
MODEL PXH-1
1006-004
158
メカ廻り
MECHANICAL DISTRIBUTION SECTION
Fig. K-7 I/O
ボード、ケーブル
I/O Board, Cable
663
662
.
661
.
650
641
.
.
681
680
.
670
.
681
680
.
670
.
See Fig.K-1
Key No.4
650
641
642
655
657
656
651
653
652
DETAIL
DETAIL
See Fig.BB-7
Key No.668
See Fig.BB-6
Key No.501
B60
B61
B62
B63
X1064
X1068
B311
B314
Y70
Y78
B6A
X1072
B106F
N07-P1
N07-P2
N07-P4
N07-P3
B86
B87
B88
B8A
S80
S81
B83
B84
B85
Y90
Y99
Y91
Y93
N09-P1
N09-P2
N09-P4
N09-P3
N09
N07
N05-P3
Y56
N05-P4
S15
U04-X009
MODEL PXH-1
1006-004
159
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
K-7
641 6300699616 ACCESSORY,P.C.B 8 831K--110-641 23L10045
642 6301401249 BRACKET 1 831K--110-642 211FA122
650 6301387550 UNIT,I/O 2 N07,09 831K--110-650 4U250191
651 6301630939 CORD 1 831K--110-651 4W204425
652 6301630946 CORD 1 831K--110-652 4W204426
653 6301630977 CORD 1 831K--110-653 4W204429
655 6301630991 CORD 1 831K--110-655 4W204431
656 6301631004 CORD 1 831K--110-656 4W204432
657 6301631011 CORD 1 831K--110-657 4W204433
661 6300007626 BOLT,HEX-SCT 2 M4X10 221A0017
662 4111414008 WASHER V 4X9X0.8 2 FW4 221H0315
663 4111412905 WASHER SPR 4 2 SW4 221H0284
670 4110418908 SCR PAN 3X6 6 831K--110-700 221E0497
680 4110864408 WASHER SPR 3 6 831K--110-720 221H0280
681 4111191909 WASHER V 3X7X0.5 6 831K--110-721 221H0311
MODEL PXH-1
1006-002
160
メカ廻り
MECHANICAL DISTRIBUTION SECTION
Fig. K-8
ラベル
Label
704
705
706
709
703
708
702
707
701
