4.3 Replacement of Cleaning Paper (How to change the cleaning paper width)
(12) Push down the lever while holding the take-up roller such that the cutout
of the left adapter can fit into the pin on the left flange of the cleaning
unit and attach the take-up roller in place.
Lever being pushed down
Fig. 4A71
Note
Because the right adapter will be disengaged easily from the roll core and
fall down, attach the supply roller, keeping it right side up.
(13) Attach the paper end securely to the roll core on the take-up side, using
a gummed cloth tape.
Roll Core Shaft
Gummed Cloth Tape, etc.
Paper Side End
Fig. 4A72
Note
Secure the paper end so that the paper side end is arranged at right angles
to the roll core shaft to take the paper up evenly on the left and right.
1-50 AKOEMT-ID
(14) Push up the lever on the take-up roller side until the roller is kept free.
(15) Rotate the take-up roller by hand and wrap the paper 2 or 3 turns
around the take-up roller.
Fig. 4A73
0609-002
4.3 Replacement of Cleaning Paper (How to change the cleaning paper width)
1-51 AKOEMT-ID
4.4 Replenishment of Industrial Alcohol
CAUTION
Be sure to turn off the power supply to the machine before work.
Only the person in charge of maintenance should perform this work.
DANGER
With the exception of industrial use alcohol, do not use cleaning
solvents.
In particular, be sure not to use gasoline by mistake as it is highly
flammable.
Reference
Refer to "1.2.1 Preparation for Cleaning" for the kinds of industrial
alcohol.
CAUTION
Industrial alcohol is likely to ignite if spilt within the machine.
•
Do not put the industrial alcohol on the machine. Otherwise, you may
spill the alcohol by mistake, causing it to flow into the inside of the
machine.
•
Do not put the industrial alcohol nor the replenishment container
inside the machine.
•
Be sure not to perform replenishment work (supplying the
replenishment container with industrial alcohol) in the machine.
•
Do not spill industrial alcohol outside the solvent tank during the
replenishment work.
•
If you have spilt solvent by mistake, clean it up with a rag as soon as
possible.
•
After cleaning up the spilt solvent, confirm that it has dried
completely and enough ventilation is provided. After that, turn on the
power switch of the machine.
•
The pressure of the air supplied to the solvent tank is set to 0.015
MPa (0.15 kgf/cm
2
).
If more than the specified pressure is applied, the tank may explode.
Be sure not to change the set pressure.
0704-003
