1-56 AKOEMT -ID 4.5 Checking of Industrial Alcohol Hose and Joints Check for industrial alcohol leakage from the hose (including the joints) running between the solvent tank and the cleaning nozzle. Check the following: …
1-55 AKOEMT-ID
Note
If air enters the tube running between the solvent tank and the discharge
nozzle, the cleaning solvent may not be discharged soon.
In this case, discharge a little amount of alcohol to let the air escape, using
the [SOLVENT DISPENSER (ON-OFF)] switch.
[SOLVENT DISPENSER (ON-OFF)] Switch
Fig. 4A80
0704-003
4.4 Replenishment of Industrial Alcohol
1-56 AKOEMT-ID
4.5 Checking of Industrial Alcohol Hose and Joints
Check for industrial alcohol leakage from the hose (including the joints)
running between the solvent tank and the cleaning nozzle.
Check the following:
• Industrial Alcohol Leakage
• Loosened or Deteriorated Hose Joints and Gaskets
• Cracks or Any Other Deterioration in Hose
Be sure to always perform this checking before starting the operation of
the machine and after completing a setup operation.
CAUTION
Industrial alcohol leaks are likely to cause fires.
•
Whenever an industrial alcohol leakage is found, turn off the power
switch of the machine immediately
.
•
When it is impossible to determine the cause of a leak or to repair
a leak, contact the marketing department or sales agency of Hitachi
High-Technologies.
•
It may be difficult to detect a leakage because industrial alcohol is a
volatile liquid.
Be sure to carefully confirm that there are no traces of leaks around
joints, etc.
0704-003
4.5 Checking of Industrial Alcohol Hose and Joints
1-57 AKOEMT-ID
4.6 Cleaning Procedure of Cleaning Unit
CAUTION
Set the [OPERATION/SET UP] switch to the “SET UP” side
before work.
Only the person in charge of maintenance should perform this
work.
When the [MAINT. EXCH.] button on the "AUTO OPN." submenu bar is
pressed, the following window appears.
Fig. 4A81
0704-003
4.6 Cleaning Procedure of Cleaning Unit
