1-63 AKOEMT -ID T able 4A18 Product/Block Name Product No. Part No. Part Name Standard and Material Q’ty Recommended # of Y ears Remarks F A Squeegee Head Section 002 630 143 4537 SOLENOID V AL VE #A39Z05-143S D0000, 31 …

100%1 / 211
1-62 AKOEMT-ID
5.2 List of Servicing Parts
Table 4A17
Product/Block
Name
Product
No.
Part No. Part Name Standard and Material Q’ty
Recommended
# of Years
Remarks
B
Table
Section
004 630 000 0245 SENSOR,
EE-SX670 3 3
005 630 032 5287 SENSOR,
EE-SX672 4 3
107 630 140 0600 MOTOR,
STEPPING
PBM603FXE20 2 5
108 630 088 5118
BALL SCREW GG1202DS-
AAPR-0134*0081
1 10
110 630 142 7164 BALL SCREW #B140099A 1 10
201 630 000 0245 SENSOR,
EE-SX670 2 3
E
PCB Chuck
Section
002 630 032 5287 SENSOR,
EE-SX672 2 3
213 630 140 0655 MOT
OR,
STEPPING
103H5210-4240 1 5
305 630 140 0679 MOTOR,
STEPPING
PBM603FCE20 1 5
310 630 143 3806 MOTOR,
AC-SERVO
#Q1AA07075DCS2
PM
1 5
311 630 139 4633 BALL SCREW #RBSK1510KU-2.6-
179LC7
3 10
319 630 152 6027 BEL
T
,
TIMING
1500-EV5GT-10 1 3
320 630 139 4640 BALL SCREW #RBSK1510KU-2.6-
312LC7
3 10
323 630 152 6010 BEL
T
,
TIMING
1165-EV5GT-20 1 3
401 630 071 7709 SENSOR,
PELEC
E3T-ST11 1 5
408 630 032 5287 SENSOR,
EE-SX672 1 3
F
Screen
Holder
Section
014 630 069 0545 SENSOR,
EE-SX674 2 3
101 630 140 0662 MOT
OR,
STEPPING
103H7126-6740 1 5
103 630 142 7195 BALL SCREW #B140101A 1 10
105 630 032 5287 SENSOR,
EE-SX672 1 3
106 630 069 0545 SENSOR,
EE-SX674 1 3
0711-003
5.2 List of Servicing Parts
1-63 AKOEMT-ID
Table 4A18
Product/Block
Name
Product
No.
Part No. Part Name Standard and Material Q’ty
Recommended
# of Years
Remarks
FA
Squeegee
Head
Section
002 630 143 4537 SOLENOID
VALVE
#A39Z05-143S
D0000, 31
1
10
101 630 140 0662 MOTOR,
STEPPING
103H7126-6740 1
5
104 630 142 7171 BALL SCREW #B140100B 1
10
105 630 032 5287 SENSOR,
EE-SX672 1 3
301
630 117 2484 CYLINDER
CDQ2B32-60DC-
A93V-XB18
2 10
FB
Screen
Recognition
Section
001 630 140 0662 MOT
OR,
STEPPING
103H7126-6740 1
5
006 630 069 0545 SENSOR,
EE-SX674 2 3
012
630 140 2413
UNIT,CAMERA
#KP-MC3AN-S2 1
013 630 140 2222 SCOPE UNIT #LA007-16-20-L43 1
014 630 140 2192 LIGHTING
UNIT
1GG4Z1
1001750-- 1
G
PEC
Recognition
001
630 088 5132 BALL
SCREW GG1220AS-BALR-
0499*0429-
1
10
003 630 140 0686 MOTOR,
STEPPING
103H7123-6710 1
5
010 630 045 6608 SENSOR,
PELEC
#E3S-LS3RC4 1 3
012 630 069 0545 SENSOR,
PHOT
O
EE-SX674 3 3
019
630 140 2413
UNIT,CAMERA
#KP-MC3AN-S2 1
020 630 140 2239 SCOPE UNIT #LA006-16-25-L36 1
021 630 140 1713 LIGHTING
UNIT
1GG4Z1
1001740-- 1
1
12 630 080 5369 SENSOR,
PM-L24 1 3
204
630 143 4551 SOLENOID
VALVE
#A35K05-146S
D0000, 31
1
10
301 630 088 5170 BALL SCREW GG1520AS-BALR-
0855*0772-
1
10
304 630 140 0662 MOTOR,
STEPPING
103H7126-6740 1
5
307 630 069 0545 SENSOR,
EE-SX674 2 3
308
630 032 5287 SENSOR,
EE-SX672 1 3
0609-002
5.2 List of Servicing Parts
1-64 AKOEMT-ID
Table 4A19
Product/Block
Name
Product
No.
Part No. Part Name Standard and Material Q’ty
Recommended
# of Years
Remarks
H
Conveyor
Section
010 630 137 8787 SENSOR,
PELEC
E3T-FD11 1
5
012 630 124 6826 SENSOR,
PELEC
E3S-LS3N 1 3
110 630 000 0252
SENSOR,
EE-SX671 1 3
1
19 630 140 0655 MOTOR,
STEPPING
103H5210-4240 2
5
210 630 137 8787 SENSOR,
PELEC
E3T-FD11 1
3
212 630 124 6826 SENSOR,
PELEC
E3S-LS3N 1 3
310 630 000 0252 SENSOR,
PHOT
O
EE-SX671 1 3
R
Cover
Section
001
630 148 1395 SWITCH,
LIMIT
D4NS-1BF 2 10
002 630 140 5506 MOTOR,DC CUDC24B4R 1
206
630 148 1395 SWITCH,
LIMIT
D4NS-1BF 1 10
M
Cleaning
Section
004 630 032 5287 SENSOR,
EE-SX672 1 3
005
630 071 7709 SENSOR,
PELEC
E3T-ST11 1 3
302 630 143 4544 SOLENOID
VALVE
#A35K05-144S
D0000, 31
1
10
303 630 141 5352 SOLENOID
VALVE
VX2120A-01-5DS1-B
1 10
K
Mechanical
Part
318 630 143 4520 SOLENOID
V
ALVE
#A35K05-145S
D0000, 31
1
10
650 630 138 7550 UNIT, I/O #UB46*001 2
0609-002
5.2 List of Servicing Parts
