Table 4A20
Product/Block
Name
Product
No.
Part No. Part Name Standard and Material Q’ty
Recommended
# of Years
Remarks
BA
Main Power
Supply
Section
001 630 140 0624 BREAKER NSE100N/20A 1
005 630 123 1303 FUSE,
SPECIAL
GP50 3
BB
Control
Board
001 630 108 3520 CIRCUIT
PROTECTOR
GV2-ME14+GV2-
AE11
2
002 630 123 0979 EM-
CONTACTOR
LC1-D09BL 5
004 423 022 8104 FUSE 250V 2A 218002 2
005 423 022 8005 FUSE 250V 1A 218001 5
006 423 022 8203 FUSE 250V
3.15A
2183.15 2
007 630 140 1
133
UNIT,DRIVER #UB48*001 1
009 630 148 7236 CIRCUIT
PROTECTOR
GV2-RT14+GV-AE11 1
019 630 143 9167 SOLENOID
VALVE
ITV1030-312S-Q 1 10
101 630 140 0594 UNIT,DRIVER #D3910 3
102 630 140 0587 UNIT,DRIVER #D3432 5
103 630 154 7558 UNIT,DRIVER #PB3A003P200-002 3
104 630 140 0648 UNIT,DRIVER MSP-2W 1
105 630 138 7550 UNIT,I/O #UB46*001 2
106 630 138 7697 UNIT,I/O #UB47*001 1
108 630 140 1157 P.C.B,MOUNT #UB49*001 1
109 630 143 3813 UNIT,DRIVER #QS1A03AA03601
P01
1
201 630 140 0785 UNIT,POWER ZWS10-12/JA 1
202 630 140 0792 UNIT,POWER ZWS10-24/JA 1
203 630 140 0525 P.C.B,MOUNT #Z2340 1
204 630 140 0808 UNIT,POWER HWS100-24/A 1
207 630 142 4439 EM-
CONTACTOR
LAD-N20 1
210 630 140 6671 UNIT,POWER HWS150-24/A 1
301 630 145 0193 P.C.B,MOUNT UB43 1
402 630 140 5506 MOTOR,DC CUDC24B4R 2
C
Control Box
Section
001 630 140 5209 EQUIPMENT #PS2000B-HTI 1
T
PCB Section
001 630 148 2484 P.C.B,MOUNT CRONOSPLUS 1
002 630 140 0761 P.C.B,MOUNT PCI-7854 1
0711-003
5.2 List of Servicing Parts
1-66 AKOEMT-ID
0609-002
2-A
AKOEMT-ID
0603-001
Chapter 2
Troubleshooting
This chapter outlines the troubleshooting.
