2-5 AKOEMT -ID 1.1.2 "PRGM. CHECK" Window • Window Layout When you select "Pattern Program Data Error" in the field under "ITEM" in the "MAC. ERR." window and press the [PRGM. CHECK…
2-4 AKOEMT-ID
[5] [RESET] Button
Pressing this button cancels an alarm (sound) and closes the "ERROR"
window.
[6] [BUZZER RESET] Button
Pressing this button cancels an alarm (sound) only.
•
Reset Procedure from "ERROR" Window
(1) T
ake notes of the descriptions under "ID", "ITEM", and "CONTENT".
Reference
When you have forgotten an error message, refer to the list of errors in the
"Machine Error Recall" tab sheet. (Operation Sequence: [RECALL MSG.]
Button (Submenu) → "Machine Error Recall" Tab Sheet)
(2) Press the [RESET] button to resume the original window.
Reference
Use the found ID as an index and refer to "2.2 Troubleshooting after Error
Display" in "Chapter 2" for details. Then, reset the machine to its normal
condition.
0603-001
1.1 "ERROR" Window
2-5 AKOEMT-ID
1.1.2 "PRGM. CHECK" Window
•
Window Layout
When you select "Pattern Program Data Error" in the field under "ITEM"
in the "MAC. ERR." window and press the [PRGM. CHECK] button, the
following window opens.
Note
When an item other than "Pattern Program Data Error" is selected and the
[PRGM. CHECK] button is pressed, nothing appears in the display field.
[1] [2] [3]
[4]
[5]
Fig. 4B3
•
Window Composition
[1] DA
TA
Displayed is the name of abnormal data.
[2] CONTENT
Displayed are the contents of an error.
[3] VALUE
Displayed is the value of abnormal data.
[4] [RESET] Button
Pressing this button cancels an alarm (sound) and closes the "ERROR"
window.
[5] [BUZZER RESET] Button
Pressing this button cancels an alarm (sound) only
.
0603-001
1.1 "ERROR" Window
2-6 AKOEMT-ID
1.1.3 "GUIDE" Window
•
Window Layout
When the [GUIDE] button is pressed in the "ERROR" window, the
following window opens.
[1] [2] [3]
[4]
[5]
Fig. 4B4
•
Window Composition
[1] LEVEL
Displayed are the levels (priority) of starting guidance messages.
[2] ITEM
Displayed are the starting guidance items.
[3] GUIDANCE
Displayed are the starting guidance messages.
[4] [RESET] Button
Pressing this button cancels an alarm (sound) and closes the "ERROR"
window.
[5]
[BUZZER RESET] Button
Pressing this button cancels an alarm (sound) only
.
0603-001
1.1 "ERROR" Window
