2-8 AKOEMT -ID 0603-001 1.1.5 "Information" Window • Window Layout When the [Information] button is pressed in the "ERROR" window , the following window opens. [1] [2] [3] [4] [5] Fig. 4B6 • Window Co…
2-7 AKOEMT-ID
1.1.4 "MAINT. STOP" Window
•
Window Layout
When the [MAINT. STOP] button is pressed in the "ERROR" window, the
following window opens.
[1] [2] [3]
[4]
[5]
Fig. 4B5
•
Window Composition
[1] DA
TE
Displayed are the date and time when the machine has stopped for
maintenance.
[2] ITEM
Displayed are the items related to the maintenance stops.
[3] CONTENT
Displayed are the contents of maintenance stops.
[4] [RESET] Button
Pressing this button cancels an alarm (sound) and closes the "ERROR"
window.
[5]
[BUZZER RESET] Button
Pressing this button cancels an alarm (sound) only
.
0603-001
1.1 "ERROR" Window
2-8 AKOEMT-ID
0603-001
1.1.5 "Information" Window
•
Window Layout
When the [Information] button is pressed in the "ERROR" window, the
following window opens.
[1] [2] [3]
[4]
[5]
Fig. 4B6
•
Window Composition
[1] DA
TE
Displayed are the date and time when the machine information is
issued.
[2] ITEM
Displayed are the items related to the machine information.
[3] CONTENT
Displayed are the contents of the machine information.
[4] [RESET] Button
Pressing this button cancels an alarm (sound) and closes the "ERROR"
window.
[5]
[BUZZER RESET] Button
Pressing this button cancels an alarm (sound) only
.
1.1 "ERROR" Window
2-9 AKOEMT-ID
2. Troubleshooting on Each Section
2.1 Easy Troubleshooting
Described below is how to troubleshoot simple problems that can be solved
by the machine operator.
When the operator cannot solve a certain problem, he/she should get in
contact with the supervisor (a person in charge of machine management).
2.1.1 Power Operation Impossible
Table 4B1
Symptom When the [POWER ON] button on the front operation panel is pressed, the
machine is not powered.
Cause (Cause 1) The [POWER ON] button on the front operation panel is not held
down for more than two seconds.
(Cause 2) The power breaker is set to “OFF”.
(Cause 3) The main air pressure has not reached “0.39MPa (4 kgf/cm
2
)".
Remedy (Remedy 1) Hold down the [POWER ON] button on the front operation panel
for more than two seconds.
Fig. 4B7
0603-001
2. Troubleshooting on Each Section
