2-38 AKOEMT-ID
(11 Input Conveyor) Table 4B29
Error ID Error Name, Description, Cause, and Remedy
1101000 Input Conveyor Width Origin
Zeroing opn. was incompleted, within specified time.
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2)
The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication with
the host CPU.
(Remedy 1) Wipe off the dirt on the sensor and zero the origin of the input conveyor width
axis again.
(Remedy 2)
It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine again.
After that, zero the origin of the input conveyor width axis. If this operation
does not reset the machine to its normal condition, the driver may be
defective. Contact our service personnel for details.
1102000 Input Conveyor Width Origin
Detect lost pulse error.
(Cause 1) The motor is overloaded and has a loss of synchronism.
(Remedy 1)
Check for any obstacle around the input conveyor width axis and perform the
zeroing operation. If this operation does not reset the machine to its normal
condition, contact our service personnel for details.
1105000 Input Conveyor Width Driver
Driver alarm signal was detected.
1108000 Input Conveyor Width Driver
Driver Over-Heat
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and restart the operation. If this operation does not reset the
machine to its normal condition, contact our service personnel for details.
1110000
Input Conveyor Width Interlock
The distance Table-X axis and inp.conv
. exceeded min.limit
(Cause 1) The table X-axis interlock sensors (B4E and B4F) are defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The conveyor width was activated when the table X axis was brought close to
the right or the left. (during the manual operation)
(Remedy 1) Check how the sensors are working in “DEVICE CHECK” window (submenu).
When the sensors are not working, it is required to replace the sensors with
new ones. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
(Remedy 3) Perform the zeroing operation and restart the operation.
0609-002
2.2 Troubleshooting after Error Display
2-39 AKOEMT-ID
Table 4B30
Error ID Error Name, Description, Cause, and Remedy
1111000 Input Conveyor Width Interlock
PCB was exist on conveyor.
(Cause 1) No operation is possible because a PCB still exists on the conveyor.
(Cause 2)
The PCB detection sensors (B40 and B41) are defective.
(Remedy 1) Remove the PCB and restart the operation.
(Remedy 2) Check how the sensors are working in “DEVICE CHECK” window (submenu).
When the sensors are not working, it is required to replace the sensors with
new ones. Contact our service personnel for details.
1112000
Input Conveyor Width Data
The data was detected outside of the possible range.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and restart the operation. If the machine is not reset to its
normal condition, shut down the power of the machine once and power up
the machine again. After that, restart the operation. When the same error still
occurs, contact our service personnel for details.
1
113000
Input Conveyor Width Origin
Zeroing Opn. Not Complete.
(Cause 1) The motor axis was activated before the zeroing operation was completed.
(Remedy 1) Perform the zeroing operation.
0609-002
2.2 Troubleshooting after Error Display
2-40 AKOEMT-ID
(12 Output Conveyor) Table 4B31
Error ID Error Name, Description, Cause, and Remedy
1201000 Output Conveyor Width Origin
Zeroing opn. was incompleted, within specified time.
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2)
The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication with
the host CPU.
(Remedy 1) Wipe off the dirt on the sensor and zero the output conveyor width axis again.
(Remedy 2)
It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine again.
After that, zero the output conveyor width axis. If this operation does not reset
the machine to its normal condition, the driver may be defective. Contact our
service personnel for details.
1202000 Output Conveyor Width Origin
Detect lost pulse error.
(Cause 1) The motor is overloaded and has a loss of synchronism.
(Remedy 1)
Check for any obstacle around the output conveyor width axis and perform
the zeroing operation. If this operation does not reset the machine to its
normal condition, contact our service personnel for details.
1205000 Output Conveyor Width Driver
Driver alarm signal was detected.
1208000 Output Conveyor Width Driver
Driver Over-Heat
(Cause 1)
Self-Diagnostics Error Message
(Remedy 1) Zero all axes and restart the operation. If this operation does not reset the
machine to its normal condition, contact our service personnel for details.
1210000
Output Conveyor Width Interlock
The distance
Table-X axis and outp.conv
. exceeded min. limit
(Cause 1) The table X-axis interlock sensors (B4E and B4F) are defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The conveyor width was activated when the table X axis was brought close to
the right or the left. (during the manual operation)
(Remedy 1) Check how the sensors are working in “DEVICE CHECK” window (submenu).
When the sensors are not working, it is required to replace the sensors with
new ones. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
(Remedy 3) Perform the zeroing operation and restart the operation.
