2-49 AKOEMT -ID (16 Self-Diagnostics ) T able 4B40 Error ID Error Name, Description, Cause, and Remedy 1601000 Control Board System error 1602000 Control Board Control board error (Cause 1) An error has occurred in the I…

100%1 / 211
2-48 AKOEMT-ID
(15 Safety Device) Table 4B39
Error ID Error Name, Description, Cause, and Remedy
1501000 Load Power Off
[Emergency] switch pressed.
(Cause 1) An [EMERGENCY ST
OP] switch was pressed.
(Remedy 1) Unlock the [EMERGENCY STOP] switch and hold down the [POWER ON]
button for more than 3 seconds. After that, press the [RESET] button in the
“ERROR” window.
1502000 Load Power Of
f
The air pressure is too low.
(Cause 1)
The main air pressure had dropped below 0.4MPa (the set value of the pressure
switch).
(Remedy 1) Adjust the pressure to the correct one.
1503000 Load Power Off
The safety door is open.
(Cause 1)
The safety door is open.
(Remedy 1) Close the safety door and hold down the [POWER ON] button for more than 3
seconds.
After that, press the [RESET] button on the touch screen. Power up
the machine again and restart the operation.
1504000 Load Power Of
f
Detected circuit breaker off.
(Cause 1)
The circuit breaker of Q100, Q202 or Q203 is turned OFF.
(Remedy 1) Contact our service personnel for details.
1505000 Load Power Of
f
Detected all load power moniter off.
(Cause 1)
The load power supply monitor (K021) is turned OFF.
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1506000 Load Power Of
f
Detected load power moniter off.
(Cause 1)
The load power supply monitor (K15) is turned OFF.
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details. If possible, check how the fuse (F01), K03, K15,
K2020 and K204 are working.
0609-002
2.2 Troubleshooting after Error Display
2-49 AKOEMT-ID
(16 Self-Diagnostics) Table 4B40
Error ID Error Name, Description, Cause, and Remedy
1601000 Control Board
System error
1602000 Control Board
Control board error
(Cause 1)
An error has occurred in the I/O communication.
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1603000
Sensor
Paste detect sensor error
(Cause 1)
The paste height detection sensor (B64) is not adjusted correctly.
(Remedy 1) Contact our service personnel for details.
1604000
System Error
Undefi
ned Error.
1605000
System Error
Illegal error code.
1606000 System Error
Internal data error
.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1)
Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1607000 System Error
Failed to caliculate position.
(Cause 1)
Self-Diagnostics Error Message
(Cause 2) The amount of the recognition correction has exceeded the limited value (10 mm
twice).
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
(Remedy 2)
Check the coordinates of the fiducial mark and the value for printing
inaccuracy correction.
0609-002
2.2 Troubleshooting after Error Display
2-50 AKOEMT-ID
Table 4B41
Error ID Error Name, Description, Cause, and Remedy
1608000 Node Error
Operation Node (1) Error
1609000 Node Error
Relay Secquence Node (2) Error
1610000 Node Error
Inp.&& Outp.Mac. Interface Node (3) Error
161
1000 Node Error
PCB Transfer Node (4) Error
1612000
Node Error
PCB Chuck Node (5) Error
(Cause 1) Node failed in the communication with the host computer.
(Remedy 1)
Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1613000 Node Error
Squeegee Head Node (6) Error
1614000 Node Error
PEC Recog. Node (7) Error
1615000 Node Error
Cleaning Unit Node (8) Error
1616000 Node Error
Blower Unit Node (9) Error
1617000 Node Error
Printing pressure control output node error
1618000 Node Error
Printing pressure control input node error
(Cause 1)
Node failed in the communication with the host computer.
(Remedy 1)
Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
0609-002
2.2 Troubleshooting after Error Display
