2-49 AKOEMT-ID
(16 Self-Diagnostics) Table 4B40
Error ID Error Name, Description, Cause, and Remedy
1601000 Control Board
System error
1602000 Control Board
Control board error
(Cause 1)
An error has occurred in the I/O communication.
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1603000
Sensor
Paste detect sensor error
(Cause 1)
The paste height detection sensor (B64) is not adjusted correctly.
(Remedy 1) Contact our service personnel for details.
1604000
System Error
Undefi
ned Error.
1605000
System Error
Illegal error code.
1606000 System Error
Internal data error
.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1)
Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1607000 System Error
Failed to caliculate position.
(Cause 1)
Self-Diagnostics Error Message
(Cause 2) The amount of the recognition correction has exceeded the limited value (10 mm
twice).
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
(Remedy 2)
Check the coordinates of the fiducial mark and the value for printing
inaccuracy correction.
0609-002
2.2 Troubleshooting after Error Display
2-50 AKOEMT-ID
Table 4B41
Error ID Error Name, Description, Cause, and Remedy
1608000 Node Error
Operation Node (1) Error
1609000 Node Error
Relay Secquence Node (2) Error
1610000 Node Error
Inp.&& Outp.Mac. Interface Node (3) Error
161
1000 Node Error
PCB Transfer Node (4) Error
1612000
Node Error
PCB Chuck Node (5) Error
(Cause 1) Node failed in the communication with the host computer.
(Remedy 1)
Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1613000 Node Error
Squeegee Head Node (6) Error
1614000 Node Error
PEC Recog. Node (7) Error
1615000 Node Error
Cleaning Unit Node (8) Error
1616000 Node Error
Blower Unit Node (9) Error
1617000 Node Error
Printing pressure control output node error
1618000 Node Error
Printing pressure control input node error
(Cause 1)
Node failed in the communication with the host computer.
(Remedy 1)
Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
0609-002
2.2 Troubleshooting after Error Display
2-51 AKOEMT-ID
Table 4B42
Error ID Error Name, Description, Cause, and Remedy
1619000 Node Error
Table Z axis motor controller node (17) error
1620000 Node Error
Table X axis motor controller node (19) error
1621000 Node Error
Table Theta axis motor controller node (21) error
1622000
Node Error
PCB Backup axis motor controller node (23) error
1623000 Node Error
T
able Chute Width axis motor controller node (25) error
1624000 Node Error
Squeegee Driving axis motor controller node (27) error
1625000
Node Error
Screen
Y axis motor controller node (29) error
1626000
Node Error
Screen Recog. X axis motor controller node (31) error
1627000 Node Error
PEC Recog.
Y axis motor controller node (33) error
1628000
Node Error
PEC Recog. X axis motor controller node (35) error
1629000 Node Error
L
Conveyor Width axis motor controller node (37) error
1630000 Node Error
R Conveyor Width axis motor controller node (39) error
(Cause 1) The motor controller node failed in the communication with the host computer.
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1631000
Pattern Program Data Error
Illegal pattern program.
(Cause 1)
An illegal value is set in the pattern program data.
(Remedy 1) Press the [PRGM. CHECK] button in the “ERROR” window and check the
contents.
After that, set the correct value.
0609-002
2.2 Troubleshooting after Error Display
