2-58 AKOEMT-ID
Table 4B49
Error ID Error Name, Description, Cause, and Remedy
1806000 PEC Recog. Camera
1806001 PEC Recog. Camera
[Camera ID] exceeds the range of setting.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and restart the operation. If the machine is not reset to its
normal condition, shut down the power of the machine once and power up
the machine again. After that, restart the operation. When the same error still
occurs, contact our service personnel for details.
1806003 PEC Recog. Camera
[Camera Gain] exceeds the range of setting.
1806004
PEC Recog. Camera
[Camera Level] exceeds the range of setting.
180601
1 PEC Recog. Camera
[Mark Size D1] exceeds the range of setting.
1806012
PEC Recog. Camera
[Mark Size D2] exceeds the range of setting.
1806014 PEC Recog. Camera
[Mark Judge Level] exceeds the range of setting.
(Cause 1)
The data has exceeded the allowable range.
(Remedy 1) Set correct parameters.
1806029
PEC Recog. Camera
Image around fi
ducial mark was unstable.
1806030 PEC Recog. Camera
Error of mark figure similitude was extensive.
1806031
PEC Recog. Camera
Error of mark similitude or mark size was extensive.
1806032 PEC Recog. Camera
Specified mark was not found in window of recog.monitor
.
(Cause 1) The fiducial marks do not conform to the coordinates X and
Y of the fiducial
marks or the recognition mark data in the pattern program.
(Remedy 1) Follow the steps below to reset the machine to the normal condition. Refer to
“Error ID “1801032”” for details.
0609-002
2.2 Troubleshooting after Error Display
2-59 AKOEMT-ID
Table 4B50
Error ID Error Name, Description, Cause, and Remedy
1806038 PEC Recog. Camera
Unavailable fiducial mark polality was set.
1806040 PEC Recog. Camera
Unavailable fiducial mark area was set.
1806043 PEC Recog. Camera
Recognition system error.
1806056 PEC Recog. Camera
Recog. transaction time over.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1)
Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1807000 Recog.
Transaction
1807001
Recog. Transaction
[Camera ID] exceeds the range of setting.
(Cause 1)
Self-Diagnostics Error Message
(Remedy 1) Zero all axes and restart the operation. If the machine is not reset to its
normal condition, shut down the power of the machine once and power up
the machine again. After that, restart the operation. When the same error still
occurs, contact our service personnel for details.
1807003 Recog. Transaction
[Camera Gain] exceeds the range of setting.
1807004
Recog. Transaction
[Camera Level] exceeds the range of setting.
180701
1 Recog. Transaction
[Mark Size D1] exceeds the range of setting.
1807012 Recog.
Transaction
[Mark Size D2] exceeds the range of setting.
1807014
Recog. Transaction
[Mark Judge Level] exceeds the range of setting.
(Cause 1)
The data has exceeded the allowable range.
(Remedy 1) Set correct parameters.
0609-002
2.2 Troubleshooting after Error Display
2-60 AKOEMT-ID
Table 4B51
Error ID Error Name, Description, Cause, and Remedy
1807029 Recog. Transaction
Image around fi
ducial mark was unstable.
1807030 Recog. Transaction
Error of mark figure similitude was extensive.
1807031
Recog. Transaction
Error of mark similitude or mark size was extensive.
1807032
Recog. Transaction
Specified mark was not found in window of recog.monitor
.
(Cause 1) The fiducial marks do not conform to the coordinates X and Y of the fiducial
marks or the recognition mark data in the pattern program.
(Remedy 1) Follow the steps below to reset the machine to the normal condition. Refer to
“Error ID “1801032”” for details.
1807038 Recog. Transaction
Unavailable fi
ducial mark polality was set.
1807040 Recog. Transaction
Unavailable fi
ducial mark area was set.
1807043 Recog. Transaction
Recognition system error
.
1807056 Recog. Transaction
Recog. transaction time over
.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
