2-72 AKOEMT-ID
(22 Others) Table 4B63
Error ID Error Name, Description, Cause, and Remedy
2201000 Vacuum Pump
Vacuum sw was not ON, within specifi
ed time.
(Cause 1) The vacuum plate is not used.
(Cause 2) Vacuum Leakage
(Cause 3) The vacuum switch is defective.
(Remedy 1) When the vacuum plate is not used, specify the vacuum plate in the pattern
program.
(Remedy 2) Check for vacuum leakage between the PCB and the vacuum plate.
(Remedy 3) The vacuum switch might be set incorrectly or the main body of the vacuum
switch might be defective. Contact our service personnel for details.
2202000
Vacuum Pump
Cleaning side change timeover
(Cause 1) The suction changeover cylinder might be malfunctioning or the cylinder sensor
might be defective.
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
2203000
Vacuum Pump
Vacuum plate side change timeover
.
(Cause 1) The suction changeover cylinder might be malfunctioning or the cylinder sensor
might be defective.
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
0609-002
2.2 Troubleshooting after Error Display
