ASM-X-Spec-SX12V2-EN-DMS

SIPLACE SX1/SX2 Specification SX1/SX2 V2 fr om SR.706, 01/2013 Edition Capacity on Demand

SIPLACE SX1/SX2

Specification SX1/SX2 V2 from SR.706, 01/2013 Edition

Capacity on Demand

SIPLACE SX1/SX2

Content

Overview of Technical Data 5

Maximum Values 5

SIPLACE SX1/SX2 6

Machine Description 6

Capacity-on-Demand 8

Modular Machine Concept SIPLACE SX1/SX2 10

Example of SIPLACE SX2 11

Example of SIPLACE SX1 with WPC5/WPC6 12

Machine Performance SIPLACE SX1/SX2 13

Placement Heads SIPLACE SX1/SX2 14

Overview 14

Standard Functions / Options 15

SIPLACE SpeedStar (C&P20) 16

SIPLACE MultiStar (CPP) 17

SIPLACE TwinStar (TH) 19

Nozzle changer 20

Technical Data 21

PCB conveyor SIPLACE SX1/SX2 22

Single conveyor 22

Flexible dual conveyor 23

Technical Data 24

I-Placement 25

Alternating placement mode 25

PCB warpage 26

Smart Pin Support 27

Component Provision SIPLACE SX1/SX2 28

Component trolley 28

Technical Data 29

X Tape Feeder Modules 30

Alternative SIPLACE Feeder Modules 31

Waffle Pack Changer (WPC5/WPC6) 32

Technical Data 33

Digital SIPLACE Vision System 34

Checking the Component Quality 35

Vision Sensor Technology 37

PCB Position Recognition 37

Bad Board Recognition 38
