65 Options List SIPLACE SX1/SX2 A vailable options SX1 SX2 Notes Flexible dua l conveyor fixed side right XX Flexible dua l conveyor fixed side left XX S peedS tar C&P20 X X In the two gantry area, only available in …
64
Standard List SIPLACE SX1/SX2
The following functions are included in the standard SIPLACE SX package:
Standard features SX1 SX2
Vacuum sensor X X
Force measurement X X
Force sensor X X
Fiducial & ink spot detection X X
Nozzle changer for the TwinStar X X
Set of TwinStar nozzles X X
Set of standard nozzles per head X X
Service box X X
Single conveyor, fixed edge right X X
Single conveyor, fixed edge left X X
Wide board
configuration
XX
Automatic electrical PCB width adjustment X X
Operation on both sides X X
LCD monitors X X
Touch-screen monitor X X
Indicator lamps X X
Tape cutter with reject bin X X
Tape separating plates X X
01005 Placement X X
Support pins X X
65
Options List SIPLACE SX1/SX2
Available options SX1 SX2 Notes
Flexible dual conveyor
fixed side right
XX
Flexible dual conveyor
fixed side left
XX
SpeedStar C&P20 X X In the two gantry area, only available in
combination with a second SpeedStar
Component camera, type 41 For the SpeedStar C&P20
Reconfiguration kit for SpeedStar X X
MultiStar CPP X X
Reconfiguration kit for MultiStar X X
Stationary component camera, type 33, 55 x 45
digital
X X For the MultiStar CPP
TwinStar X X
High-Force Head X X
Reconfiguration kit for TwinStar or High-Force
head
XX
Stationary component camera, type 25, 16 x 16
digital
X X Only for TwinStar or high force head
Very High Force Pick&Place (VHF) available on
request
On request
12 segment Collect&Place (C&P12) On request
Vision teaching station X X
Nozzle changer X X Depending on the placement head
Nozzle changer, row 2 X X Depending on the placement head
Sensor for the component reject bin X X
Component trolley SIPLACE SX 60 X X
Smart Feeder, 2x8 mm, 12 mm and 16 mm All X feeder modules can be used without
restrictions on the SIPLACE SX.
X feeder modules, 4 mm to 88 mm X X
Splice point recognition for X feeder modules X X
Linear Dip Module LDU X X X Not in combination with SpeedStar
Support for an additional tape reel,
SIPLACE SX
XX
66
Options List SIPLACE SX1/SX2
Available options SX1 SX2 Notes
Feeder module adapter for the X-series X X Use this adapter to install tray stack feed-
ers, roadrunners, multi stick feeders, S lin-
ear vibratory feeders and label presenters
in the component trolley of SIPLACE SX
machines.
110/208 V conversion kit X X
Vacuum pump
a
a) Available on request.
X X Not for the TwinStar or high force head and
the MultiStar
Vacuum pumpinstallation kit
a
XX
WPC5/WPC6 X X In SIPLACE SX1 only at location 1.
Not in combination with SpeedStar.
In placement area with 2 gantries the fol-
lowing applies to the MultiStar: MultiStar on
the side opposite the WPC5 and TwinStar
on the same side as the WPC5/WPC6.
Component trolley SIPLACE SX 30 X X At WPC5/WPC6 in respective location.
1D board barcode readers X X
2D board barcode readers X X
External presetup location
a
XX
Dummy feeder module X X
“Long Board” option (LBO) for single conveyors X X The "Long Board" option facilitates the
placement of boards which are longer than
the specified length, up to a length of 850
mm.
“Long Board” option (LBO) for dual conveyors X X
Whispering Down the Line (WDTL) X X
Capacity-on-Demand X X
3-part signal lamp X X
3D coplan X X For Twin Head and Multistar, max. 1x per
machine
Board barcode X X
Smart Pin Support X X
