Version 2
Page 12 / 17 24.11.2021
Version 2
Page 13 / 17 24.11.2021
Pos. Item no. Description Part marking
03055282-01 GR HMI /P001
2 03078913-04 MONITOR SCD1520-TDC SPARE PART
3 03059594-03 USB-KEYBOARD ACTIVE KEY WITH
TOUCH-PAD
SPARE PART
03055289-01 GR CONTROL ELEMENTS /P001
03055265-02 CONTROL ELEMENT EMERGENCY
STOP
SPARE PART
00328233-01 SWITCH ELEMENT 3SB34 / 1NC SPARE PART
7 03033143-05 FAULT INDICATOR LAMP SPARE PART
8 03004316-01 CONNECTION ELEMENT INCL.
CLOSING COVER
9 03004318-01 PERMANENT LIGHT ELEMENT
GREEN
03099236-01 LED BULB SOCKET B15D 24V AC/DC
CLEAR
SPARE PART
03086329-01 CONTROL ELEMENT START/STOP
DX1/2
03042332-01 SWITCH ELEMENT 2NO 3SB3400 SPARE PART
00328232-01 SWITCH ELEMENT 3SB3400-0B 1NO
SCREW TER.
SPARE PART
14 03083987-02 GR COVERING P001
15 03042552-01 ISO 4762 - M 4 X 10-A2-70 STANDARD PARTS
16 03045200-01 DIN EN ISO 7380-M4 X 6-A2-70 STANDARD PARTS
17 03074575-01 OUTER COVER RIGHT
18 03047654-01 CONTACT DISC -4-FST-
FLZNNC-480H
19 03074573-01 OUTER COVER LEFT
20 03047654-01 CONTACT DISC -4-FST-
FLZNNC-480H
21 00341997-01 LABEL GROUNDING POINT GNYE
D12.5
22 03074562-02 SIDE COVER CPL
23 03072728-01 BUFFER WITH PIN, TYP-NR. 1284 STANDARD PARTS
24 03072700-01 CLAMPING PART
25 03067568-02 BUFFER, COVER-GUIDE SPARE PART
26 03078701-01 LOCKING PLATE CPL.
27 03077824-02 SEALING FOR NGR FAN
28 03074780-02 FAN ASSEMBLY
Version 2
Page 14 / 17 24.11.2021
Pos. Item no. Description Part marking
29 03052317-02 FAN HOOD 1-PIECE SPARE PART
30 03091773-01 AXIAL FAN 24 V DC
31 03072748-01 SUPPORT, SAFETY SWITCH CPL.
32 00341997-01 LABEL GROUNDING POINT GNYE
D12.5
33 03068040-01 EDGE PROTECTION, CORNER PART
RIGHT
34 00306732-01 PUSH BUTTON INNER HALF PS-1,
10.3MM
35 03047654-01 CONTACT DISC -4-FST-
FLZNNC-480H
36 03045200-01 DIN EN ISO 7380-M4 X 6-A2-70 STANDARD PARTS
37 03045194-01 DIN EN ISO 7380-M3 X 6-A2-70 STANDARD PARTS
38 03054128S01 DIN EN ISO 10511 - M3-A2-70 Spare Part
39 03065055-03 GUIDE RAIL HORIZONTAL SPARE PART
40 03054371-01 NIROSTA-HINGE GN 237.5-40-40
41 00304455-01 DIN 988-6X12X0,5-ST 2 K 50 STANDARD PARTS
42 03047654-01 CONTACT DISC -4-FST-
FLZNNC-480H
43 03068956-01 COVER, EXIT SIDE
44 03065813-01 SUPPORT GCU CPL.
45 00341997-01 LABEL GROUNDING POINT GNYE
D12.5
46 03075573-01 SUPPORT BOX-PC
47 03066144-01 BUFFER BOX-PC
48 03075578-01 ANGLE BRACKET
49 00316904-01 DIN 125-A 3,2-140HV-A2
50 03077029-02 ASSEMBLY, COVER BARCODE SPARE PART
51 03077031-02 COVER BARCODE
52 03078081-01 SIDE COVER COMPLETE
53 03055262-04 HOOD SWITCH /B SERIES SPARE PART
54 03055263-01 SAFETY SWITCH AZ 16-03ZVRK-M16
3NC
SPARE PART
03009407-01 COUNTER-NUT SKINTOP / M16X1.5
00365923-01 CABLE GLAND M16X1.5 2-7MM PA
SILVER GREY
00321650-01 BALL HOLDER 2053 F. AZ15/16
58 03057763-02 GAS PRESSURE SHOCK ABSORBER SPARE PART
