YSM20_KLW_pl - 第50页
6 10 9 3 8 7 5 1 4 2 12 11 13 14 Ejector (HM) Head KL W -1504 No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date 1 KL W -M7151-02 EJECTOR,RESIN 1 2 KLF-M7152-00 V AL VE 1 3 KLF-M7153-00 V AL VE 1 4 KL W …
2
3
12
4
7
3
1
6
3
4
9
3
1
11
5
7
8
6
8
3
1
6
3
2
10
3
1
3
Z Axis Assy (HM)
Head
KLW-1410
5-10
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90990-28J078
WASHER,PLAIN
4
2
90K41-001400
LABEL,CAUTION
2
3
91312-05014
BOLT HEX,SOCKET HEAD
8
4
91312-06022
BOLT HEX,SOCKET HEAD
4
5
91312-06060
BOLT HEX,SOCKET HEAD
2
6
99480-04008
PIN,PARALLEL
4
7
99480-06014
PIN,PARALLEL
4
8
KHY-M71G3-00
SHAFT 1
2
9
KLW-M7103-00
PLATE,HEAD
1
10
KLW-M71G1-00
SIDE PLATE,R
1
11
KLW-M71G2-00
SIDE PLATE,L
1
12
KLW-M71G5-00
Z UNIT ASSY.
10
6
10
9
3
8
7
5
1
4
2
12
11
13
14
Ejector (HM)
Head
KLW-1504
No. Part No. Part Name Q'ty Remarks
Compati. Revision No.-date
1 KLW-M7151-02 EJECTOR,RESIN 1
2 KLF-M7152-00 VALVE 1
3 KLF-M7153-00 VALVE 1
4 KLW-M7154-00 BIT 1
5 KLW-M7156-00 BIT CAP 1
6 KLW-M7157-00 EJECTOR 1
7 KLW-M7158-00 VALVE 1
8 KLW-M715A-00 MUFFLER 1
9 KLW-M715B-00 GASKET 1
10 KLW-M8527-00 FILTER 1
11 KHY-M4592-01 VAC SENSOR BRD ASSY 1
12 90563-23J060 SPACER 4
13 KLW-M74T1-00 TUBE 1 04-205mm
14 KLW-M7155-00 FILTER CAP 1
5-11
33
13
14
8
16
3
5
24
9
28
1
22
10
2
31
20
6
31
17
29
4
7
12
25
9
6
18
7
30
4
27
26
21
11
23
19
3
15
32
34
35
Scan Camera / Axis (HM)
Head
KLW-1409
5-12
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
1
2
90112-02J006
BOLT HEX,SOCKET HEAD
1
3
90112-2AJ005
BOLT, HEX.SOCKET HEAD
4
4
90990-01J106
BOLT HEX,SOCKET HEAD
4
5
90990-01J107
BOLT HEX,SOCKET HEAD
4
6
90990-08J018
SCREW, PAN HEAD
3
7
90990-08J020
SCREW, PAN HEAD
4
8
90K41-001320
LABEL,CAUTION
1
9
91312-03005
BOLT HEX,SOCKET HEAD
4
10
91312-03006
BOLT HEX,SOCKET HEAD
4
11
91312-03008
BOLT HEX,SOCKET HEAD
6
12
KHY-M7554-12
OF.LIGHT BRD.ASSY.
1
13
KHY-M7905-10
OF.SV.LIGHT BRD ASSY
1
14
KHY-M7A13-02
DIFFUSER, MAIN
1
15
KHY-M7A16-01
COVER,PRIZM
1
16
KHY-M7A31-01
BLOCK,LIGHT SIDE
1
17
KHY-M7A34-01
DIFFUSER, SIDE
1
18
KLW-M66JA-00
HNS,SCAN FLEX
1
19
KLW-M78H1-00
PLATE,CABLE
1
20
KLW-M78H2-00
BRACKET,CABLE
1
21
KLW-M78H3-00
TAPE,SCAN CABLE
1
22
KLW-M78H5-00
BRACKET,CONNECTOR
1
23
KLW-M78H6-00
PLATE,CLAMP
1
24
KLW-M78H7-00
COVER,SENSOR
1
25
KLW-M78H8-00
CLAMP,CABLE
1
26
KLW-M78H9-00
BRKT.,FIX
1
27
90990-08J026
SCREW, PAN HEAD
4
28
90990-11J001
SCREW, PAN HEAD W/W
1
29
90990-28J002
WASHER,PLAIN
3
30
91312-04005
BOLT HEX,SOCKET HEAD
2
31
91312-04025
BOLT HEX,SOCKET HEAD
4
32
91312-05010
BOLT HEX,SOCKET HEAD
2
33
KLW-M7850-00
SC MOTOR ASSY.
1
34
KLW-M78C0-00
SCAN CAM. ASSY.,CX.
1
35
KLW-M78H0-00
HNS.SCAN ASSY.
1
