YSM20_KLW_pl - 第76页
10 7 6 3 3 3 13 11 12 5 12 1 13 11 13 12 3 2 10 11 8 9 9 3 8 10 2 9 2 8 3 2 1 4→14 11 5→15 11 1 10 11 9 2 10 2 8 9 3 8 2 9 7 6 8 3 2 10 7 1 3 6 4 2 3 2 10 7 6 3 3 3 13 11 12 5 12 1 13 11 13 12 3 2 10 11 8 9 9 3 8 10 2 9 …
20
26
21
22
23
18
14
15
11
10
5
4
8
9
16
3
7
3
19
7
1
9
25
2
6
6
10
12
17
5
13
15
8
24
Width Base (L)
Conveyor
KLW-1410
7-21
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$KM-11
MUFFLER
1
2
$TSH6-01
JOINT
1
3
90112-2AJ005
BOLT, HEX.SOCKET HEAD
4
4
91312-04006
BOLT HEX,SOCKET HEAD
2
5
91312-04010
BOLT HEX,SOCKET HEAD
3
6
91312-04025
BOLT HEX,SOCKET HEAD
3
7
91312-05010
BOLT HEX,SOCKET HEAD
5
8
91312-05040
BOLT HEX,SOCKET HEAD
8
9
91312-06022
BOLT HEX,SOCKET HEAD
4
10
92902-04600
WASHER,PLAIN
2
11
KLC-M910N-00
SPACER
1
12
KLF-M915B-00
SPACER
1
13
KLW-M9156-00
PLATE,STOPPER
1
14
KLW-M915G-00
DUCT,CABLE
1
15
KLW-M9174-00
PLATE
2
16
KLW-M917G-00
STAY,DUCT
1
17
KLW-M917M-00
DAMPER
1
18
KLW-M917N-00
DAMPER
1
19
KLW-M917P-00
BRKT.,DUCT
1
20
KLW-M917Y-00
PLATE,VALVE
1
21
KLW-M91B4-A0
CONV.BASE SUB ASSY.4
1
22
KLW-M91G1-A0
STOPPER SUB ASSY.1
1
24
KLW-M91VA-B0
VALVE DS LR-L ASSY
1
L-R
25
KLW-M91VB-A0
VALVE DS RL-L ASSY
1
R-L
26
KLW-M91G5-A0
DUCT SUB ASSY.1
1
10
7
6
3
3
3
13
11
12
5
12
1
13
11
13
12
3
2
10
11
8
9
9
3
8
10
2
9
2
8
3
2
1
4→14
11
5→15
11
1
10
11
9
2
10
2
8
9
3
8
2
9
7
6
8
3
2
10
7
1
3
6
4
2
3
2
10
7
6
3
3
3
13
11
12
5
12
1
13
11
13
12
3
2
10
11
8
9
9
3
8
10
2
9
2
8
3
2
1
4→14
11
5→15
11
1
10
11
9
2
10
2
8
9
3
8
2
9
7
6
8
3
2
10
7
1
3
6
4
2
3
2
Sensor-board detection
Conveyor
KLW-1410
7-22
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
97602-03310
SCREW PAN HEAD W/WASHER
8
2
98502-03005
SCREW PAN HEAD
24
3
KLF-M9156-01
HOLDER, SENSOR
12
4
KLW-M653H-00
SEN.L1 CV RIGHT ASSY
2
4-1
KLW-M653H-00
SEN.L1 CV RIGHT ASSY
1
After the Y34600
OK
MM40199-2015/5/7
5
KLW-M653J-00
SEN.DS CV LEFT ASSY
2
5-1
KLW-M653J-00
SEN.DS CV LEFT ASSY
1
After the Y34600
OK
MM40199-2015/5/7
6
KLW-M653P-00
SENSOR DS CV1 ASSY (Fiber+Amp)
1
KLW-M653R-00(Amp)KHM-M654B-01(Fiber)
7
KLW-M653P-10
SENSOR DS CV2 ASSY (Fiber+Amp)
1
KLW-M653R-10(Amp)KHM-M654B-01(Fiber)
8
KLW-M653P-40
SENSOR DS CV5 ASSY (Fiber+Amp)
2
KLW-M653R-40(Amp)KHM-M654B-01(Fiber)
9
KLW-M653P-50
SENSOR DS CV6 ASSY (Fiber+Amp)
2
KLW-M653R-50(Amp)KHM-M654B-01(Fiber)
10
KLW-M653P-80
SENSOR DS CV9 ASSY (Fiber+Amp)
2
KLW-M653R-80(Amp)KLW-M915A-00(Fiber)
11
KLW-M653P-90
SENSOR DS CV10 ASSY (Fiber+Amp)
2
KLW-M653R-90(Amp)KHM-M654B-01(Fiber)
12
KLW-M653P-C0
SENSOR DS CV13 ASSY (Fiber+Amp)
1
KLW-M653R-C0(Amp)KHM-M654B-01(Fiber)
13
KLW-M653P-D0
SENSOR DS CV14 ASSY (Fiber+Amp)
1
KLW-M653R-D0(Amp)KHM-M654B-01(Fiber)
14
KLW-M653U-401
SEN.L1 CV RIGHT ASSY
1
After the Y34600
OK
MM40199-2015/5/7
15
KLW-M653U-601
SEN.DS CV LEFT ASSY
1
After the Y34600
OK
MM40199-2015/5/7
4
9
3
7
7
6
1
11
2
12
17
17
10
2
17
2
14
17
14
17
15
18
8
12
6
1
9
11
13
18
16
5
3
2
10
9
11
10
14
12
14
2
5
17
1
3
2
6
17
12
17
15
18
8
11
1
6
13
9
18
16
2
10
4
3
2
Extension conveyer
Conveyor
KLW-1410
7-23
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
91312-03008
BOLT HEX,SOCKET HEAD
12
2
91312-03010
BOLT HEX,SOCKET HEAD
24
3
91312-03014
BOLT HEX,SOCKET HEAD
8
4
KLV-M917S-00
GUIDE
2
5
KLV-M917T-00
GUIDE
2
6
KLW-M913A-A0
PULLEY ASSY.
6
7
KLW-M9157-00
BRKT.,SENSOR
2
L-R
8
KLW-M917W-00
BRKT.,SENSOR
2
R-L
9
KLW-M9521-00
FRAME,CONVEYOR
4
10
KLW-M9523-00
PLATE,GUIDE
4
11
KLW-M9524-00
PLATE,GUIDE
4
12
KLW-M9525-00
PLATE,JOINT
4
13
KLW-M9527-00
PLATE,HNS.
2
14
KLW-M957H-00
BELT,CONVEYOR
4
15
91312-04006
BOLT HEX,SOCKET HEAD
4
16
91312-04008
BOLT HEX,SOCKET HEAD
4
17
91312-04012
BOLT HEX,SOCKET HEAD
16
18
92902-04200
WASHER,PLAIN
8
