3 7 Push Up Conveyor Unit KGM-081 1 18 13 5 4 1 1 3 7 8 1 43 3 2 7 8 33 34 10 7 15 16 14 12 39 42 41 9 6 45 44 12 12 40 38 35 26 24 32 27 25 31 17 9 46 18 22 37 29 30 28 36 9 28 20 23 21 19 No. Part No. Part Name Q'…
2
7
Stoppers
Conveyor Unit
KGM-081118
1
8
4
9
8
7
5
2
10
6
6
3
EXIT Stopper Sub Stopper, Fixed
11
1
8
4
9
8
7
14
13
2
10
6
6
3
12
15
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M9281-10X PLATE-2, SUB STOPPER 2
2 KV7-M9282-00X STOPPER, SUB 2
3 KV7-M9283-00X CYL., YMDA16X35 2
4 KV7-M9284-02X BRKT., SENSOR 2
5 KGK-M927A-00X SENSOR, UP 1
6 $SL4-M5 JOINT 4
7 91314-03005 BOLT HEX.SOCKET HEAD 8
7-1 91312-03005 BOLT HEX.SOCKET HEAD 8 (2006/1/16) MBY0158 OK
8 91317-03012 BOLT HEX. SOCKET HEAD 8
9 91317-04008 BOLT HEX. SOCKET HEAD 4
10 91317-04040 BOLT HEX. SOCKET HEAD 4
11 KGK-M927B-00X SENSOR, LOW 1
12 KV7-M9285-00X SPACER 2
12-1 90990-41J104 COLLAR 2 (2008/4/11) ME30019 OK
13 KV7-M9284-10X NUT PLATE, SENSOR 2
14 KGM-M928A-00X SENSOR, UP 1
15 KGM-M928B-00X SENSOR, LOW 1
3
7
Push Up
Conveyor Unit
KGM-081118
13
5
4
11
3
7
8
1
43
3
2
7
8
33
34
10
7
15
16
14
12
39
42
41
9
6
45
44
12
12
40
38
35
26
24
32
27
25
31
17
9
46
18
22
37
29
30
28
36
9
28
20
23
21
19
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M9201-00X BRACKET, MOTOR
1
2 KV7-M9202-00X STAY, ADJUST
1
3 KV7-M9203-00X SHAFT 1
2
4 KV7-M9205-01X PULLEY 1:P22-3GT
1
5
KV7-M9206-00X WASHER
1
5-1 90990-28J076 WASHER 1 (2007/12/18) MDX0125 OK
6 90K63-331512 AC SERVO MOTOR
1
7 90933-01J200 BEARING
6
8 99009-10400 CIRCLIP :
2
9 91317-04010
BOLT HEX. SOCKET HEAD
14
10 91317-04022 BOLT HEX. SOCKET HEAD
2
11 91317-05014 BOLT HEX. SOCKET HEAD
4
12 91317-05016 BOLT HEX. SOCKET HEAD
2
13 91317-04012 BOLT HEX. SOCKET HEAD
1
14 KV7-M9204-00X SHAFT 2
1
15 91317-06060 BOLT HEX. SOCKET HEAD
1
16 92907-06200 WASHER PLAIN
1
17 KV7-M9207-00X FRANGE 1
3
18 KV7-M9208-00X FLANGE 2
3
19 KV7-M9209-01X PULLEY 2:P60-3GT
3
20 KV7-M9211-00X HOUSING
3
21 KV7-M9212-00X COLLAR 2 1
21-1 90990-41J060 COLLAR 1 (2008/4/17) ME20197 OK
22 KV7-M9213-00X NUT
3
23 KV7-M9214-00X SCREW
3
24 KV7-M9215-00X JOINT
3
25 KV7-M9217-00X FLANGE
3
26 KV7-M9218-00X SPRING
3
27 KV7-M921C-00X ROLLER
3
28 90933-01J905 BEARING
6
29 99009-42500 CIRCLIP
3
30 99009-25400 CIRCLIP
3
31 91317-05020 BOLT HEX. SOCKET HEAD
24
32 92A08-03306 SCREW, SET
3
33 KV7-M9219-00X STOPPER
1
34 KV7-M921B-00X BOLT,STOPPER 1
34-1 90990-33J011 BOLT,STOPPER 1 (2008/6/18) ME20019 OK
35 KV7-M920D-00X DOG
1
36 KV7-M920E-00X BRACKET
1
37 KGA-M921G-00X SENSOR, ORG
1
38 91317-04008 BOLT HEX. SOCKET HEAD
2
39 KGM-M920A-00X PLATE
1
40 91317-05012 BOLT HEX. SOCKET HEAD
16
41 KGM-M920C-00X STAY
1
42 KGA-M921T-00X BOLT
4
43 KV7-M921A-01X BELT:1299-3GT-15
1
44 95304-10700 NUT HEXAGON 4
44-1 95302-10700 NUT HEXAGON 4 (2006/2/17) MBY0200 OK
45 KV7-M921D-10X PUSH UP PIN UNIT
9
46 92907-10600 WASHER PLAIN 3
4
7
Clamp Board
Conveyor Unit
KGM-081118
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M9261-01X PLATE 1, LINK
4
2 KGM-M9262-00X PLATE BOARD CLAMP
2
3 KGM-M9263-00X PLATE 2, LINK
2
4 KV7-M9264-01X LINK 4
4-1 KV7-M9264-02X LINK 4 (2005/10/17) MB00045 OK
5 KV7-M9265-01X SPACER, COLLAR
4
6 KV7-M9266-01X GUIDE
6
7 KV7-M9267-01X COLLAR 2 4
7-1 90990-41J064 COLLAR 4 (2008/4/17) ME20197 OK
8 KV7-M9268-00X PIN 4
8-1 KV7-M9268-01X PIN 4 (2007/6/18) MD60100 OK
8-2 90990-18J017 PIN,PARALLEL 4 (2007/11/30) MD00140 OK
9 KV7-M9269-02X CYLINDER
2
10 KV7-M926A-01X JOINT, CYL
2
11 KV7-M926B-01X COLLAR JOINT 4
11-1 90990-41J065 COLLAR 4 (2008/4/17) ME20197 OK
12 KV7-M926C-01X STOPPER, CYLNDER
2
13 KV7-M926D-01X JOINT, CYL. BRKT.
2
14 KV7-M926E-01X BRKT. , CYL.
2
15 98904-03004 SCREW BINDING HEAD 8
15-1 98902-03004 SCREW BINDING HEAD 8 (2006/1/9) MBY0166 OK
16 91317-03008 BOLT HEX. SOCKET HEAD
4
17 91317-04014 BOLT HEX. SOCKET HEAD
10
18 92907-03200 WASHER PLAIN
4
19 92907-04600 WASHER PLAIN
4
20 KGM-M926H-00X PLATE, 1
2
21 KV7-M926K-00X BOLT,1 24
21-1 90169-02JB04 SCREW, BINDING HEAD 24 (2007/11/9) MD00082 OK
22 92017-04010 BOLT, BUTTON HEAD
2
23 $UEF4BU JOINT 4
5
6
6
6
8
1
19
18
16
7
4
1
15
15
2
8
18
19
19
21
21
20
21
21
21
17
4
7
5
17
16
17
3
11
22
11
10
12
9
14
13
23
