KGM_YGD_PL - 第21页
1 10 Dot Station (OP .) Dot Station (OP .) KGM-081 1 18 3 15 5 23 22 8 22 12 27 27 24 13 33 11 14 2 18 35 35 38 32 42 41 43 44 21 36 36 16 7 1 28 37 30 30 37 28 16 17 31 35 35 39 39 39 39 25 16 10 29 4 16 17 31 25 20 19 …
1
9
Mainte Accessory
Mainte Accessory
KGM-081118
11
16
15
14
13
17
18
10
9
10
8
5
6
1
2
3
12
4
7
7
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1
KV7-M66V4-01X HNS, 24-4
1
PREVIOUS
2 KV7-M66V5-01X HNS, 24-5 1 NEXT
3 KV7-M66V6-00X HNS, 24-6 1 CONTACT
4
KG3-M7120-00X GLUE CHARGE UNIT
1
5 KG3-M7118-00X PISTON 1
6
91317-05090 BOLT HEX. SOCKET HEAD 1
7 KU4-M8590-00X AIR GUN ASSY 1
8 KU4-M8593-00X TAC VALVE 1
9 $AN4 JOINT 1
10 $TSH4-M5 JOINT 2
11 $TE4-R URETHANE TUBE 1 1000mm
12 KM4-M3810-00X NEEDLE, PIERCE UNIT 1
13 KM4-M3801-00X NEEDLE, PIERCE 0.29 1
14 KM4-M3801-10X NEEDLE, PIERCE 0.35 1
15 KM4-M3801-20X NEEDLE, PIERCE 0.45 1
16
KM4-M3801-30X NEEDLE, PIERCE 1.0
1
17
KM4-M3801-40X NEEDLE, PIERCE 0.7
1
18
KM4-M3801-50X NEEDLE, PIERCE 1.4
1
1
10
Dot Station (OP.)
Dot Station (OP.)
KGM-081118
3
15
5
23
22
8
22
12
27
27
24
13
33
11
14
2
18
35
35
38
32
42
41
43
44
21
36
36
16
7
1
2837 30
30
37
28
16
17
31
35
35
39
39
39
39
25
16
10
29
4
16
17
31
25
20
19
13
26
34
40
13
9
6
36
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1
KGE-M9301-00X CASE 1
1
2 KGE-M9302-00X CASE 2 1
3 KGE-M9303-00X CASE 3 1
4
KK3-M9304-01X DIFFUSER
1
5 KK3-M9305-00X PAPER GUIDE 1 5
6
KK3-M9307-00X BLOCK 1 1
7 KGE-M9308-00X STAY 1 1
8 KK3-M9309-00X ROLLER 1
9 KK3-M9310-00X SPRING 1
10 KK3-M9311-00X GEAR 1 1
11 KK3-M9312-00X GEAR 2 1
12 KK3-M9313-00X GEAR 3 1
13 KK3-M9314-00X SHAFT 1 3
14 KK3-M9315-00X SHAFT 2 1
15 KK3-M9316-00X SHAFT 3 1
16
KK3-M9317-00X GUIDE 1
4
17
KK3-M9318-00X GUIDE 2
5
18
KK3-M9319-00X REEL 1
1
19 KK3-M9320-00X REEL 2 1
20 KK3-M9321-00X REEL 3 1
21 KW7-M9360-00X DOT ST. BOARD ASSY. 1
22 KK3-M9324-00X FLANGE 2
23 KK3-M9325-00X ROLLER 1
24
KK3-M9326-00X SHAFT 4
1
25
KV6-M9327-00X FOOT
2
26 KK3-M9329-00X BELT 1
27 KK3-M9331-00X BRG. 4
28 KK3-M9332-00X SENSOR 2
29 KGE-M9333-00X MOTOR ASSY 1
30 KGE-M9309-00X STAY SENSOR 2
31 KK3-M9335-00X MAGNET 2
32 92A08-03003 SET SCREW M3X3 1
33 92A08-04006 SET SCREW M4X6 2
34 KM4-M9330-01X ROLL PAPER 1
35 KK3-M9337-00X PLATE 4
36 91317-03006 BOLT HEX. SOCKET HEAD 7
37
91317-03010 BOLT HEX. SOCKET HEAD
4
38 91318-04030 BOLT HEX. SOCKET HEAD 4
39 91317-05012 BOLT HEX. SOCKET HEAD 8
40 KGE-M9338-00X RING, GUIDE 1
41 KGE-M9339-00X BASE, MIRROR 1
42 KGE-M9340-00X MIRROR 1
43 90563-03J050 SPACER BOLT 4
44
95302-03600 NUT HEXAGON
4
1
11
Control Box
Controller
KGM-081118
4
1
8
7
2
3
5
6
16
13
12
11
3
9,14
10,15
OLD
15
OLD
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGN-M4510-00X MOTHER BOARD ASSY 1
2 KGN-M5840-01X SERVO BOARD ASSY 1
2-1 KGN-M5840-02X SERVO BOARD ASSY 1 (2005/2/18) MB20070 OK
2-2 KGN-M5840-04X SERVO BOARD ASSY 1 (2006/4/10) MC40013 OK
3 KGK-M4200-00X SYSTEM UNIT ASSY 1
3-1 KGS-M4200-00X SYSTEM UNIT ASSY 1 (2006/3/15) MC20176 NG
3-2 KGS-M4200-10X SYSTEM UNIT ASSY 1 (2006/4/24) MC40043 OK
3-3 KGS-M4209-A0X SPARE SYSTEM UNIT 1 1 Spare (SI 0703002) (2007/11/15) MD90073 OK
4 KGK-M5810-21X DRIVER BOARD ASSY 1
5 KGJ-M441H-11X VISION BOARD ASSY 1
5-1 KGJ-M441H-12X VISION BOARD ASSY 1 (2004/3/2) M420149 OK
6 KGR-M4530-11X INTERFACE BOARD ASSY 1
7 KGN-M5880-00X D.POWER BOARD ASSY 1
8 KW3-M4256-00X CD-ROM DRIVE 1
8-1 Delete Spare only (2012/4/10) MHY0031
9 KGN-M4230-00X FLASH BOARD ASSY 1
9-1 Delete (2006/3/15) MC20176
10 KGK-M4265-00X FLASH ASSY 512MB 1
10-1 KGK-M4255-00X FLASH DISK 1 (2004/10/20) MA00085 OK
10-2 Delete (2005/11/10) MB00101
11 KGA-M5303-00X SW POWER DC5 1 PAA150F-5
11-1 KGS-M5303-00X SW POWER DC5 1 PBA150F-5 (2007/1/22) MCY0159 NG
12 KV1-M5303-11X SW POWER DC12 1
13 KGA-M4185-10X FAN MOTOR ASSY 2
14 KGN-M4230-00X FLASH BOARD ASSY 1
14-1 Delete (2006/3/15) MC20176
15 KGK-M4265-10X FLASH ASSY 1GB 1
15-1 KGK-M4255-20X FLASH DISK 1 (2004/10/20) MA00085 OK
15-2 KHL-M4255-00X FLASH DISK 1 (2007/6/20) MD60085 OK
16 KJ0-M4134-10X PANEL NO SERVO 1
