SAMSUNG TECHWIN Page 27 CP45NEO C onveyor Ass’y Part Photo J7053214C BRACKET1-SENSOR J7053275A PCB GUIDE COVER J7053219B BRACKET-MOTOR J7053736A BRACKET SENSOR PLACE (E3S-LS3N) J7053244A DOG ADJUST J7053742A PCB STOPPER
