CP45NEO Technical Reference_CS_Ver - 第52页
SAMSUNG TECHWIN Page 52 CP45NEO H ead Ass’y Part Photo J3108008A SERVO MOTOR [P30B04010DXS00] J6607051A LM GUIDE J3211020A FIBER SENSOR [FT-FM2] J7055141A SPLINE SHAFT J3211028A TEACHING BEAM LIGHT [LS20-05] J7055147A PI…
Part List
SAMSUNG TECHWIN
Page
51
CP45NEO
Head Ass’y
NO. LEVEL PART NO. PART NAME Q'TY TYPE
Old No. Stock
Reference
76 ..2
J7155346A FIDUCIAL CAMERA BASE [J7155346A]
1
J7155346A
○
SAMSUNG TECHWIN
Page
52
CP45NEO
Head Ass’y
Part Photo
J3108008A SERVO MOTOR [P30B04010DXS00]
J6607051A LM GUIDE
J3211020A FIBER SENSOR [FT-FM2]
J7055141A SPLINE SHAFT
J3211028A TEACHING BEAM LIGHT [LS20-05]
J7055147A PIN
SAMSUNG TECHWIN
Page
53
CP45NEO
Head Ass’y
Part Photo
J7055151A ARM JOINT
J7055162A MIRROR PIN
J7055153A MIRROR SCREW
J7055169B Z-SENSOR BRACKET
J7055155A MIRROR JOINT-RIGHT
J7055170A
SAFETY SENSOR BRACKET
