SAMSUNG TECHWIN Page 55 CP45NEO H ead Ass’y Part Photo J7155168A JOINT J7155178A PULLEY-THETA-1 J7155168B JOINT J7155179C PULLEY-THETA-2 J7155171B MOTOR BRACKET Z-1 J7155192A CAMERA BRACKET (LEFT)
SAMSUNG TECHWIN
Page
54
CP45NEO
Head Ass’y
Part Photo
J7055204A ARM JOINT
J7055268A ARM SPRING BRK(L)
J7055205A MIRROR JOINT-LEFT
J7055269A ARM SPRING BRK(R)
J7055208B SENSOR BRACKET
J7154110B BOARD PLATE
SAMSUNG TECHWIN
Page
55
CP45NEO
Head Ass’y
Part Photo
J7155168A JOINT
J7155178A PULLEY-THETA-1
J7155168B JOINT
J7155179C PULLEY-THETA-2
J7155171B MOTOR BRACKET Z-1
J7155192A
CAMERA BRACKET (LEFT)
SAMSUNG TECHWIN
Page
56
CP45NEO
Head Ass’y
Part Photo
J7155201D LOWER COVER
J7155225A SIDE ILLUMINATOR COVER
J7155201F LOWER COVER
J7155467B SIDE 조명 BRACKET
J7155220A
MOTOR HEAT ISOLATOR 2
J7159108A BLOCK-LED
