SAMSUNG TECHWIN Page 56 CP45NEO H ead Ass’y Part Photo J7155201D LOWER COVER J7155225A SIDE ILLUMINATOR COVER J7155201F LOWER COVER J7155467B SIDE 조명 BRACKET J7155220A MOTOR HEAT ISOLATOR 2 J7159108A BLOCK-LED
SAMSUNG TECHWIN
Page
55
CP45NEO
Head Ass’y
Part Photo
J7155168A JOINT
J7155178A PULLEY-THETA-1
J7155168B JOINT
J7155179C PULLEY-THETA-2
J7155171B MOTOR BRACKET Z-1
J7155192A
CAMERA BRACKET (LEFT)
SAMSUNG TECHWIN
Page
56
CP45NEO
Head Ass’y
Part Photo
J7155201D LOWER COVER
J7155225A SIDE ILLUMINATOR COVER
J7155201F LOWER COVER
J7155467B SIDE 조명 BRACKET
J7155220A
MOTOR HEAT ISOLATOR 2
J7159108A BLOCK-LED
SAMSUNG TECHWIN
Page
57
CP45NEO
Head Ass’y
Part Photo
J9055046A NOZZLE HOLDER ASS'Y J9055050A-AS BALL SPLINE UNIT J9060079B
HEAD SIDE 조명 BOARD ASS'Y
J7055156D ILLUMINATOR SHAFT
