NPM-W2 EJM7DE-MB-02O-00
First layer Second layer Third layer Fourth layer
2-2-2-12
Preparation
Head
Conveyor
Dispensing head
(Dispensing head)
Input addresses are displayed in the
unit of bits.
Output addresses are displayed in the
unit of bits.
Returns all axes to the origin.
Checks the current positions and
status of all the axes controlled by the
machine.
Checks the temperature control unit
(temperature) and Electro pneumatic
regulator (pressure).
Replaces the nozzle.
Checks the machine for normality
with the aid of head motions.
Checks the valve status and actuate
each valve on a stand-alone basis.
Adjusts the conveyor width to the
desired one.
Transfers PCBs.
Changes the lane to adjust.
(Displays only for dual lane)
Whole
Adjustment
Machine
menu
Edits measurement coordinates due
to a local height measurement
action and checks PCB conditions.
Local height
NPM-W2 EJM7DE-MB-02O-00
First layer Second layer Third layer Fourth layer
2-2-2-13
HeadCamera
Multi-
recognition
camera
Compo-
nent
names
Menu configuration 7
Operating procedure
2-2-2
Engineer mode 5
Displays multi-recognition camera
status and related information.
Machine
menu
Adjustment
Checks all recognition operations.
Displays head camera status and
related information.
Displays LED light status and related
information.
Displays the capture status of the
head camera and related information.
Configures the settings for
communication with LNB.
Whole
Configures the conditions for the
whole system operations.
Configures the indicating lamp and
buzzer settings.
Configures the indicating lamp and
buzzer settings during production or
under suspension.
Configures the monitor settings.
Setup
Tray
Checks tray unit operation.
Displays information on the feeders
installed to the machine.
Checks the motions of the feeders
installed to the machine.
Feeder
NPM-W2 EJM7DE-MB-02O-00
First layer Second layer Third layer Fourth layer
2-2-2-14
Configures the defect beam settings
for the XY unit and the time variation
correction settings.
XY unit
Configures optional functions.
Head
Configures the parameters to move
the head vertically.
Checks and configures the defect
head status.
Conveyor
Configures the optional functions of
conveyors.
Configures the parameters.
Feeder
Configures optional functions.
Configures the parameters.
Configures optional functions.
Configures the parameters.
Tray
Configures optional functions.
Configures the optional functions.
Configures parameters of head
up/down actions.
Checks and configures conditions of
a defect head.
Head
(Dispensing
head)
Preparation
Head
camera
Configures the parameters.
