NPM-W2 EJM7DE-MB-02O-00
2-3-3-4
5
Confirm the message
1
2
2
4
Select a file
Insert the SD card (parameter
disk)
6
3
Select a lane
：Lane 1
：Lane 2
4 537
Loading data from SD card to the machine/Dual lane mode
Load production data to the machine with the SD card inserted.
7
Data check
：Production data name of lane 1
：Production data name of lane 2
NOTE
●If you use only one lane for production,
load the production data only for one
lane.
●You cannot load neither alternate
mode nor independent mode for front
and rear lanes at once. (→P. 2-3-2)
6
■If you do not load data
Preparation
NPM-W2 EJM7DE-MB-02O-00
File
opera-
tion
Saving production data
Saving data from the machine to DGS via LNB
2
Operating procedure
2-3-4
1
1
Modify data
2-3-4-1
Confirm the message
This explains how to save production data, loaded from LNB to the machine, to DGS via LNB after modifying
the production data in the machine.
2
■Not to save the data
■To cancel
(remains in a state of )
1
NPM-W2 EJM7DE-MB-02O-00
Saving data from the machine to SD card
2-3-4-2
2
1
3
2
Confirm the message
This explains how to save production data, loaded from LNB to the machine, to the SD card after
modifying the production data in the machine.
1
Check whether the SD card
(parameter disk) is inserted
3
■If you do not save the data
(remains in a state of )
2
Preparation
