NPM-W 2 EJM7DE-MB-02O-0 0 Color Network Data loading Line status Red Disco nnected － ・ An error is occurring (including a communicatio n error) Green Connected Enable ・ idling Yellow Connected Disable ・ Under prepara tio…
NPM-W2 EJM7DE-MB-02O-00
2-3-6-2
:Save
1
3
4
Select data load or save
:Load
1
3
2
2
Select a lane
：Lane 1
：Lane 2
5
Data check
Dual lane mode
4
5
：Production data name of lane 1
：Production data name of lane 2
Preparation
NPM-W2 EJM7DE-MB-02O-00
Color Network
Data
loading
Line status
Red Disconnected
－
・An error is occurring
(including a communication error)
Green Connected Enable
・idling
Yellow Connected Disable
・Under preparation
・Production data being modified
Gray Connected Disable
・Under suspension
・Waiting for components supply
・Waiting for a process
・Production is under way
A
2-3-7-1
A
Status of each machine
This explains how to check the status of each machine in the whole line.
1
1
File
opera-
tion
Line status check
操作編
2-2-4
操作編
2-3-3
Operating procedure
2-3-7
B
B
●Cancel download reservation of the
production data. Displays only on the
first machine in line.
NPM-W2 EJM7DE-MB-02O-00
2-3-7-2
Preparation
