Describes how to start production. It is the operator’s daily task.
Check that the emergency stop switch is released.
●To release, make sure that danger or
abnormality is removed, and then turn the
switch to the right.
1
Check before operation
Check that there is no foreign
matter on the conveyor or the
feeder table.
5
Self-diagnosis is conducted
4
■For abnormal case
Abnormal items are displayed .
(→P.3-1-1
-2)
■For normal case
Origin return is carried out.
Check that the front and
rear safety covers are
closed.
2
3
Start production
ENABLING
START
1
2
3
Production
start
■For alternate mode
For independent mode
(→P.3-1-1
-2)
NPM-W EJM2DE-MB-03O-05
When errors are found by self-diagnosis
1
2
1
Choose the item
(The modification method is displayed)
2
Modify error as instructed
3-1-1-2
For independent mode
1
(The independent mode is displayed)
2
Select a lane
2
To start production in front and
rear lanes:
To start production only in lane 1:
To start production only in lane 2:
1
Production
NPM-W2 EJM7DE-MB-03O-00
Produc-
tion
Production start 2
Operating procedure
3-1-1
Move the Y-axis
Move the X-axis of which the feeder cart is detached until its end comes on the retract position
seal of the Y-axis
3-1-1-3
Retract position seal
X-axis end
2
1
OFF
SERVO
4
SERVO
ON
5
3
6
To
How to start production using an axis on the opposite side when the feeder cart is detached
■The machine without the independent changeover support unit (movable cover) (option)
Even though the feeder cart is detached in independent mode, production using an axis on the opposite side is
enabled. The preparation is described here.
Production is also enabled with the feeder cart attached.
Start production after attaching the feeder cart
■The machine with the independent changeover support unit (movable cover) (option)
