NPM-W 2 EJM7DE-MB-03O-0 0 3-2-2 -4 Production
NPM-W2 EJM7DE-MB-03O-00
3-2-2-3
C
A
D
C
A
Items on the table is switched to the ones
related to inspection information.
Bad pattern
●Rate: Defect patterns/Produced patterns
●Quantity: Defect patterns
Inspection information (inspection head only)
B
B
Bad PCB
●Rate: Defect PCBs/Produced PCBs
●Quantity: Defect patterns
D
Bad components [ppm]
●Rate: Defect components/(Produced
PCBs x Inspection components in PCB)
●Quantity: Defect components
Produc-
tion
informa-
tion
Operating procedure
3-2-2
Operating information
2
NPM-W2 EJM7DE-MB-03O-00
3-2-2-4
Production
NPM-W2 EJM7DE-MB-03O-00
2
3-2-3-1
C
A
B
D
E
F
G
You can check component pickup information of a feeder per feeder address.
Produc-
tion
informa-
tion
Operating procedure
3-2-3
TBL (table)
Table to be referred.
ADR (address)
Feeder address.
CompName
Component name being
picked up.
Total
Total of pickup count of all feeders and
error count, and error occurrence rate
for total pickup count.
H
E FD
A C HB
Shows the rest of the component name
by scrolling.
PickupCnt
Number of components being picked
up per feeder.
Err Cnt
Number of components resulting in
error
Err Rate
Error occurrence rate for pickup count
Feeder pickup
information 1
●Perform on both and .
1
G
I
●Numerical number: Feeder position
number
●R/L/C: Feeder component position
(For double tape feeder, thin type single
feeder)
R(right), L(left),
(For stick feeder)
R(right), L(left), C(center)
Tape feeder
●A/B: Tray feeder table
(Only A is available in a single tray
feeder)
● Numerical number: Tray pallet
position number
Tray feeder
Lane
Change the display item to “All” or
“Lane”. When you select “Lane”, also
select the lane by the lane change
button.
I
