NPM-W 2 EJM7DE-MB-03O-0 0 Produc- tion informa- tion Operating procedure 3-2-4 You can ch eck component pick up information o f a noz zle per he ad. 3-2-4 -1 Head pic kup inf or ma tion 1 C A B TBL (table) A table referr…
NPM-W2 EJM7DE-MB-03O-00
3-2-3-4
7
■To check the data
8
(The recognition error image is displayed)
■To save the data
9
10
11
Confirm the message
or
Confirm the message
■When you do not save the data
■To cancel
12
10
11
8 9 12
●You can check the image per nozzle
resulting in error and save the data.
Select the nozzle position
Production
NPM-W2 EJM7DE-MB-03O-00
Produc-
tion
informa-
tion
Operating procedure
3-2-4
You can check component pickup information of a nozzle per head.
3-2-4-1
Head pickup
information 1
C
A
B
TBL (table)
A table referred to.
G
H
Shows the previous or next table.
NozzlePos
Nozzle installation position number of a
head.
●Perform on both and .
Nozzle No
Nozzle type being picked up
Total
Total of pickup count of all heads and
error count, and error occurrence rate for
total pickup count.
2
1DA C
HG
B E
F
I
D
E
F
Pickup Cnt
Number of components being picked up
per head
Err Cnt
Number of components resulting in error
Err Rate
Error occurrence rate for pickup count
Lane
Change the display item to “All” or
“Lane”. When “Lane” is selected, also
select the lane by the lane change
button.
I
NPM-W2 EJM7DE-MB-03O-00
3-2-4-2
B
1
(Error detailed information is displayed)
A
Changes the display type.
D
Returns to the previous screen.
E
C
Total
Total of pickup count/rate of all heads,
or total / rate of error count of each
head.
A
C
EDB
Total Err
Total / rate of error count per head
Error item
(→P.3-2-3-2)
