NPM-W 2 EJM7DE-MB-04O-0 0 A TBL (table) B Changer Pos. A C 4-4-3 -11 B D E F E Err cnt F Err Rate D InspectNum C Nozzle No. 1 Inspection monitor 6 Operating procedure 4-4-3 Produc- tion Position of nozzles inside the noz…

100%1 / 714
NPM-W2 EJM7DE-MB-04O-00
4-4-3-10
1
B
A
C
D
G
H
E
F
I
J
A
B
TBL (table)
(Displays detailed error information)
Returns to the previous screen.
DC E F G H I J
The number of flip-over inspection errors.
The number of foreign body inspection
errors.
The number of different component
inspection errors.
(Currently not in use)
The number of polarity inspection errors.
The number of other errors.
The number of presence/absence
inspection errors.
The number of displacement inspection
errors.
Nozzle position in the placement head.
Foreign body
Different component
Flip-over
Presence/absence
Position
Polarity
Other
Position
Component
inspection
NPM-W2 EJM7DE-MB-04O-00
A
TBL (table)
B
Changer Pos.
A C
4-4-3-11
B D E F
E
Err cnt
F
Err Rate
D
InspectNum
C
Nozzle No.
1
Inspection monitor 6
Operating procedure
4-4-3
Produc-
tion
Position of nozzles inside the nozzle
changer.
In the cases such as these, where certain nozzles produce a high concentration of defects, the components
judged as defective are checked on a per-nozzle basis so that they are utilized to identify and take measures
against the causes of defects.
The number of inspected components
judged as defective.
(Err cnt / InspectNum) × 100 (%)
Nozzle
NPM-W2 EJM7DE-MB-04O-00
4-4-3-12
1
C
D
G
H
E
F
I
J
A
B
TBL (table)
B
A
(Displays detailed error information)
Returns to the previous screen.
DC E F G H I J
The number of flip-over inspection errors.
The number of foreign body inspection
errors.
The number of different component
inspection errors.
(Currently not in use)
The number of polarity inspection errors.
The number of other errors.
The number of presence/absence
inspection errors.
The number of displacement inspection
errors.
Nozzle position in the placement head.
Foreign body
Different component
Flip-over
Presence/absence
Position
Polarity
Other
Position
Component
inspection
