NPM-W2 EJM7DE-MB-06O-00
6-1-8-6
2
D
C
E F
A
B
A
CompName
Tolerance of a component size,
pickup/ mount information
B
(→P.6-1-8-2)
C
D
Lead width
Choose a lead group.
Tolerance of lead width on upper, right
lower and left sides.
E
Lead float
F
Lead pitch
Tolerance of lead float.
Tolerance of lead pitch on upper, right
lower and left sides.
G
G
Returns to the previous screen.
3
Confirm and edit the detailed data.
Confirm and edit the recognition option
data.
(→P.6-1-8
-3)
(→P.6-1-8
-1)
Setting
change
NPM-W2 EJM7DE-MB-06O-00
6-1-8-7
AB
F
E
D G
C
C
A
B
CompName
Reel of lead
Side
The number of leads of each side.
Choose a side to check a component.
D
Lead information
Lead existence of each component.
F
G
H
H
Returns to the previous screen.
Data
editing
Component shape data
edit 4
Component with leads 2
E
Displays the screen to set “Missing
lead” position.
Displays the screen to set “Noise”
position.
Displays the screen to set “Lead
existence” position.
Lead
information
Symbol Setting button
Lead
existed
○
Lead
absence
×
Noise N
Operating procedure
6-1-8
1 2 3 4 ･･･
Top side
1
2
3
4
･
･
･
･･･ 43 2 1
Right
side
Bottom side
1
2
3
4
･
･
･
Left
side
The lead order is clockwise direction as a
reference.
4
Confirm and edit the missing lead
information.
NPM-W2 EJM7DE-MB-06O-00
6-1-8-8
●Set this even though it is judged to
lead absence, it is actually lead
existed.
Set a start position of
missing lead and lead count
I
J
K
JK I
Returns to the screen in .
4
It is reflected as [X] in lead
information .
D
Set a start position of lead
noise and lead count
L
M
It is reflected as [N] in lead
information .
D
Set a start position of lead
existence and lead count
N
O
It is reflected as [○] in lead
Information .
D
■Missing lead setting screen
■Noise position setting screen
■Lead existence setting screen
MK L
OK N
Setting
change
