NPM-W 2 EJM7DE-MB-06O-0 0 6-2-8 -4 Setting change
NPM-W2 EJM7DE-MB-06O-00
+
9
9
(The pickup position to be carried
out in teach is saved)
10
10
6-2-8-3
Produc-
tion data
teaching
Pickup position
learning teach 2
Operating procedure
6-2-8
11
Confirm the message
11
■When you do not save the data
NPM-W2 EJM7DE-MB-06O-00
6-2-8-4
Setting
change
NPM-W2 EJM7DE-MB-06O-00
Produc-
tion data
teaching
Placement coordinates
teach 1
6-2-9-1
Generally placement check must be performed before production. It is necessary to edit the data by
performing placement coordinates teaching in any of the following conditions;
●visually check a placed PCB and placement displacement will be found
●check coordinates of PCB hole and component pin before placing such as PGA
Choosing a teaching mode
■Mount
Because the position of a certain component is displaced, edit the placement position.
■Mount/Pattern
Because the same position of a component on multifaceted PCBs is displaced, edit the
placement position.
■Origin offset
Because the placement positions of all components are displaced to the same direction, edit the
placement positions.
●Before teaching, make sure the data registered in the machine is correct.
●Keep the data properly after teaching to use the data for the production data.
NOTICE
Operating procedure
6-2-9
Placement position
Placement data
Placement position
Placement data
Placement position
Placement data
●Origin offsets that teach has been
performed are all reflected to all
components
