NPM-W2 EJM7DE-MB-07O-00
Unit
setting
Option setting 1
7-1-1-1
Operating procedure
7-1-1
1 2A
A
1
2
For temporary suspended
option setting
Choose the settings of each
item
The previous or next table is
displayed.
B
A
Option item set status
(The description of the selected item
is displayed)
■To enable the item
■To disable the item
Entire condition of system actions is configured.
You can set either ON or OFF on each item.
B
1) Some options are not available depending on the model. In such cases,
the multi recognition camera is to be used instead.
1)
NPM-W2 EJM7DE-MB-07O-00
7-1-1-2
System
administration
No. Item name Function when [ON] is selected
1 Quality trace
Transfers the log files including pickup/mounting orders and correction
values to the LNB during automatic operation.
2
Comm. abnormality
MC stop
Stops the NPM machine if communication with the LNB is broken.
3
Operation mode
Switch SD
Displays a message requesting the key disk (SD) when an attempt is made
to switch the operation mode to Engineer. Insert the key disk to switch to the
Engineer mode.
4 Parts trace
Sends the parts trace information to the LNB once the operation is started.
The information to be sent include the part information that is written to the
tape feeders whenever production of a PC board has been finished, and the
mounted part information by mounting point.
5
Screen print SD
output
Pressing the print screen switch saves the screenshot onto an SD card.
6
Empty Parts Auto
Screen Transition
If a “parts empty” error has occurred, the display automatically switches to
the reminder monitor screen of the part component concerned.
7
Empty Parts Auto
Screen Transition
(with stock)
If a “parts empty” error has occurred, the display automatically switches to
the reminder monitor screen of the part component concerned.
8
Auto product change
(option)
Performs production changeover (loading production data, replacing nozzles
and support pins, and adjusting the conveyor rail width, etc.) automatically.
9
Auto product change
PCB bar code recog
(option)
Recognizes barcodes on PCBs by the head camera to perform production
changeover automatically.
10
In again when auto
product change
Permits the production data to be downloaded when switching the production
data in cases where the ‘Auto product change’ function is used and defective
PC boards are reloaded after repair.
11
NG part Eject before
mounting
Ejects parts judged to be NG such as pickup error, recognition error or raised
lead, before mounting.
12
Inspection MC feed
back (option)
Displays the feedback information (warning or error information) from the
inspection machine after mounting.
Setting information 1
●Default：OFF
■Whole
NPM-W2 EJM7DE-MB-07O-00
7-1-1-3
No. Item name Function when [ON] is selected
13
Production
information not
picking up
management
Counts up all pickups attempted including parts empty and empty pockets of
the spliced tape feeders.
14
When parts for one
piece of PCB is being
supplied, restart
operation
When the machine has stopped due to a “parts empty” error, this option
allows production to be resumed by just replenishing at least one of the
exhausted feeders.
15
Mount speed escape
action
Allows the X/Y-axis to be retracted at the mounting speed for the part being
picked up when the machine has comes to a single stop due to a cushion
end error or mounting error.
16
Keep PCB recog lamp,
changing data
Keeps using the lamp value recorded in the machine, without performing
auto lamp teaching at PCB recognition during production changeover for
each machine.
17
PCB recognition lamp
value communication
set
Applies the lamp value recorded in the upstream machine to all downstream
machines, without performing auto lamp teaching at PCB recognition during
production changeover for each machine.
18
Return action
(when production
schedule pieces are
completed)
Returns the nozzles and trays at the end of automatic operation after the
scheduled production is reached.
19
Style and pickup
angle set freely
Enables the tape feeder or tray style (angle) and tray pickup angle (for 2-/3-
nozzle heads only) to be set in 1-degree increments.
20
Vacuum sensor error
opposing lane product
continue
If, in the independent mounting mode, the machine comes to a single stop
due to mounting error or vacuum sensor error caused by dropped part, this
option allows the opposing lane to continue production.
21
Auto log off in
production
Enables the automatic log off function during production.
22
Transfer error
opposing lane product
continue
Allows production on the opposing lane to continue even if a PCB transfer,
pickup, or position error has occurred.
23
PCB warp clamp 0
calibration
Generates the curved surface for PCB warp correction with the heights of
clamp positions as 0.
24
Change parts gap
action
(short distance)
Sets the range of measurement with the [Parts gap confirm] button on the
Parts recog. teach screen to “100 x 100 mm”.
Setting information 2
Unit
setting
Option setting 2
Operating procedure
7-1-1
● Default ：OFF
■Whole
