NPM-W2 EJM7DE-MB-07O-00
7-1-2-10
Setting information 9
System
administration
■Feeder (3/5)
Type Item Description Initial
value
Setting
range
Determine
Tape cutting length (F)
[mm]
Setting value used to cut tape during
automatic operation. Tape is cut when the
longest empty tape on the front table
exceeds this value.
100
10.0 to
2000.0
Tap cutting length (R)
[mm]
Setting value used to cut tape during
automatic operation. Tape is cut when the
longest tape on the rear table exceeds this
value.
100
10.0 to
2000.0
Feeder mainte qty
(8 mm) [ten thousand]
When the maintenance count has reached
this value with feeder maintenance warning
ON, operation cannot be continued.
100 1 to 500
Feeder mainte qty
(12/16 mm) [ten
thousand]
100 1 to 500
Feeder mainte qty
(24/32mm)
[ten thousand]
When the maintenance count has reached
this value with feeder maintenance warning
ON, operation cannot be continued.
100 1 to 500
Feeder mainte qty
(44/56mm)
[ten thousand]
100 1 to 500
Feeder mainte qty
(72mm)
[ten thousand]
100 1 to 500
Feeder mainte qty
(88/104/120mm) [ten
thousand]
100 1 to 500
NPM-W2 EJM7DE-MB-07O-00
7-1-2-11
Setting information 10
Unit
setting
Action parameter
setting 6
Operating procedure
7-1-2
■Feeder (4/5)
Type Item Description Initial
value
Setting
range
Determine
Feeder mainte
warning rate[%]
The number of times a feeder has been
maintained exceeds the quantity obtained by
“Feeder mainte qty x Setting value”, a feeder
maintenance warning is displayed.
●If 100% is set, only warning is displayed.
100 0 to 100
Pickup position
reteaching
deviation [%]
When the joint part of splicing is detected
and fed at once, and pickup position
automatic teaching is carried out, if the chip
size of MAX L and MAX W exceeds the
value (%) automatic teaching retry is carried
out as recognition result out of area error.
This is used only if the joint part of splicing is
detected and fed at once.
●Iｆ 0 is set, if the chip size of MAX L and
MAX W exceeds ±1mm, it results in error
and no retry is carried out as usual.
0 0 to 100
Splicing no-check stop
length [mm]
This is the stop length from the joint
detection position in splicing no-check.
●When 0 is set, the joint detection position
becomes the immediate stop position.
●When values other than 0 are set, it
becomes in the warning state and stops at
the length of the set value.
●This function is valid for the feeder
firmware version of 530 or later.
0 0 to 100
Parts empty judge
remains[%]
When the part empty pickup reaches to the
error count, if the number of remaining parts
is not below this set value, the machine
does not judge as parts empty. In this case,
pickup error is also counted.
0
0.000 to
99.999
Splicing judge remains
[%]
Even though splicing is detected, if the
remaining amount is not below this set
value, the machine does not judge as
splicing.
●With 0 set, if splicing is detected, the
machine judges as splicing without any
condition.
0
0.000 to
99.999
NPM-W2 EJM7DE-MB-07O-00
7-1-2-12
Setting information 11
System
administration
■Feeder (5/5)
Type Item Description Initial
value
Setting
range
Determine
Auto Tape Moving
Remain [%]
Even if parts are fed as many times as the
set value after the remaining number of the
parts being used reaching 0, information on
all parts in the splicing unit will be reflected
in the unit where parts are used if any splice
joint is not detected.
●Enabled when feeder verification or
remaining warning is set to ON
00 to 15
The remains when the
joint not pass is
selected[%]
When the machine stops after the number
of remaining parts reaches “1”, selecting
“the join not pass” sets the “default value x
the setting value” as the remaining number
of parts.
0
0.0 to
100.0
Unfixed cnt. before
Splicing [piece]
Ignores as many errors as the number of
the parts set at the trailing edge of the reel
on the machine side after completion of
splicing.
Because the improper taping of splicing
tape is likely to cause pickup errors, this is
used to ignore such errors as an unstable
zone.
00 to 3
Feed length
(8mm) [mm]
When production starts, the number of
chips obtained from specified length / pitch
is compared with the number of chips
currently set on workpiece exhaust, and the
larger one is applied for the number of
workpiece exhaust chips.
● Applicable feeder: 8mm or less (Paper,
embossed)
0
0.0 to
120.0
Pickup position gap
retry count
When a pickup position gap has occurred, a
retry can be attempted in combination with
pickup position teaching as many times as
specified by this setting value.
00to5
■Transfer (1/2)
Type Item Description Initial
value
Setting
range
Mechanic
Transcription unit film
formation speed
[mm/s]
The maximum speed for forming film. 75 0 to 500
Transcription unit
taking out speed
[mm/s]
The maximum speed for scraping and
retracting.
150 0 to 500
