NPM-W2 EJM7DE-MB-07O-00
7-1-2-12
Setting information 11
System
administration
■Feeder (5/5)
Type Item Description Initial
value
Setting
range
Determine
Auto Tape Moving
Remain [%]
Even if parts are fed as many times as the
set value after the remaining number of the
parts being used reaching 0, information on
all parts in the splicing unit will be reflected
in the unit where parts are used if any splice
joint is not detected.
●Enabled when feeder verification or
remaining warning is set to ON
00 to 15
The remains when the
joint not pass is
selected[%]
When the machine stops after the number
of remaining parts reaches “1”, selecting
“the join not pass” sets the “default value x
the setting value” as the remaining number
of parts.
0
0.0 to
100.0
Unfixed cnt. before
Splicing [piece]
Ignores as many errors as the number of
the parts set at the trailing edge of the reel
on the machine side after completion of
splicing.
Because the improper taping of splicing
tape is likely to cause pickup errors, this is
used to ignore such errors as an unstable
zone.
00 to 3
Feed length
(8mm) [mm]
When production starts, the number of
chips obtained from specified length / pitch
is compared with the number of chips
currently set on workpiece exhaust, and the
larger one is applied for the number of
workpiece exhaust chips.
● Applicable feeder: 8mm or less (Paper,
embossed)
0
0.0 to
120.0
Pickup position gap
retry count
When a pickup position gap has occurred, a
retry can be attempted in combination with
pickup position teaching as many times as
specified by this setting value.
00to5
■Transfer (1/2)
Type Item Description Initial
value
Setting
range
Mechanic
Transcription unit film
formation speed
[mm/s]
The maximum speed for forming film. 75 0 to 500
Transcription unit
taking out speed
[mm/s]
The maximum speed for scraping and
retracting.
150 0 to 500
NPM-W2 EJM7DE-MB-07O-00
Unit
setting
Action parameter
setting 7
Operating procedure
7-1-2
Setting information 12
■Multi-recognition camera
Type Item Description Initial
value
Setting
range
Determine Recog. OK rate [%]
This is a criterion used to judge recognition
results good or bad.
If “ANS” of recognition results falls short of it,
a recognition error occurs.
85 0 to 100
Type Item Description Initial
value
Setting
range
Mechanic
Tray pickup place gap
[mm]
This gap is added in pickup from trays. 0.5 -2.0 to 2.0
■Tray
7-1-2-13
■ Transfer (2/2)
Type Item Description Initial
value
Setting
range
Timer
Time Keep thick film
time [s]
Coating thickness formation holding time
for the transcription unit.
30 0 to 600
Stamp material
Spill Detect Invalid
Time (F) [s]
After transcription materials at the front side
are automatically supplied, spill detection is
disabled during the set time period.
●It assumes the time between the start of
material dripping off and until dripping off
stops.
0.5 0.0 to 5.0
Stamp material
SpillDetect Invalid
Time (R) [s]
After transcription materials at the rear side
are automatically supplied, spill detection is
disabled during the set time period.
●It assumes the time between the start of
material dripping off and until dripping off
stops.
0.5 0 .0 to 5.0
NPM-W2 EJM7DE-MB-07O-00
7-1-2-14
System
administration
■Height sensor
Type Item Description Initial
value
Setting
range
Determine
PCB warpage grade
tolerance [%]
When PCB warpage is measured, if the
tolerance obtained form the height
measurement value exceeds the set value,
the single stop error occurs.
0.5 0.0 to 10.0
Local height result
tolerance [mm]
When the local height on the several
locations are measured, if the minimum and
maximum values exceed the set value, the
single stop error occurs.
0.5 0.1 to 2.0
Setting information 13
