NPM-W2 EJM7DE-MB-07O-00
■If air blow and the vacuum pressure
measurement results in error
Confirm the message
(The background of the measured value
of the corresponding nozzle is
displayed in yellow.)
7-2-6-2
+
2
(Air blow and the vacuum pressure of
each head (nozzles are removed) are
measured)
System
administration
■If air blow and vacuum pressure
measurement completes without error
[Cleaning blow complete] is displayed
in .
F
NPM-W2 EJM7DE-MB-07O-00
Unit
adjust-
ment
Vacuum output check
(placement head)
7-2-7
1
You can change the valve and check whether each of the vacuum pumps and air blows operates normal
individually.
+
1
+
+
+
BA C
A
B
C
BC
Operating procedure
7-2-7
Air flow value
Nozzle air flow value.
Check the air flow value during
vacuuming or blowing
■To turn ON/OFF the vacuum pump
(The vacuum pump is switched ON/OFF)
■With the vacuum pump turned ON, to
turn ON/OFF only the vacuum valve
of a specified nozzle
(The vacuum pressure is displayed in the
field below)
■With the vacuum pump turned ON,
to turn ON/OFF only the vacuum
break valve of a specified nozzle
(The pressure for the vacuum break is
displayed in the field above)
■To turn ON/OFF the cleaning blow
(The cleaning blow valve is switched
ON/Off)
Vacuum valve
Vacuum break valve
● , in 7-2-6 is displayed in
terms of 8-bit.
B
B
C
：“Sensor value” ：“Full”
●Perform on both and .
NPM-W2 EJM7DE-MB-07O-00
2 3
Syringe status check
(dispensing head)
7-2-8
1
You can check the status of each unit installed on the dispensing head.
1
F G
Confirm the status of each unit
BA C D E
A
Thermal Regulator Status
The temperature control status of each
nozzle.
B
Material Status
The parts-empty detection status of each
nozzle.
C
Current temp(℃)
The current temperature of the
temperature control unit attached to the
syringe of each nozzle.
D
Set temp(℃)
The desired temperature for the
temperature control unit attached to the
syringe of each nozzle.
E
Pressure(MPa)
The electropneumatic regulator pressure
applied to the syringe of each nozzle
2
Choose the desired syringe pos.
to check action
F
The dispensing valve turns ON/OFF for
the nozzle
G
The heater control of the temperature
control unit turns ON/OFF for the nozzle.
3
+
●Checks the material-empty status.
Unit
adjust-
ment
Operating procedure
7-2-8
System
administration
