NPM-W 2 EJM7DE-MB-07 O-00 7-2-13 -4 System administration
NPM-W2 EJM7DE-MB-07O-00
7-2-13-3
I
1
I
Rem.
The number of remaining components in
a feeder.
Checking memory status
1
J
K
L
M
N
O
J K L M N O
Unit
adjust-
ment
Feeder information
check 2 (intelligent feeder)
Operating procedure
7-2-13
ADR (Address)
Position to install a feeder.
Origin offset
The second origin offset of each feeder.
Tape Feed
The take-up length of a tape inside a
feeder.
●Unit: mm
Feed Count
The amount of feed.
The previous or next table is displayed.
or
Switches between the maintenance
count of a feeder and the total feed
count.
■Only for the double tape feeder or the thin
type tape feeder.
NPM-W2 EJM7DE-MB-07O-00
7-2-13-4
System
administration
NPM-W2 EJM7DE-MB-07O-00
Unit
adjust-
ment
Tray feeder action
check
7-2-14-1
A
B
D
You can check actions of each function in a tray feeder.
C
1
2
Operating procedure
7-2-14
Lifter position
Pallet number on Lifter.
If the above button is pressed after
selecting the [Lifter position] or [Supply
position, [None] is shown in the
corresponding field.
Selected pallet
Selected pallet number.
●The ejection pallet is displayed as [21].
Supply position
Pallet number at Supply position.
Choose a pallet
Check action
1
A C DB
2
E
F
E
Switches between Tray A/B.
■For the twin tray feeder
■Not displayed in the case of the single
tray feeder.
