NPM-W 2 EJM7DE-MB-07 O-00 Nozzle position Offset of the selected nozzle is displayed in . 7-3-6 Machine parame- ter B Placement head You can check the X/Y/ θ element offset values (calibrat ion result) per head θ rotatio…
NPM-W2 EJM7DE-MB-07O-00
7-3-5-2
A B C
B
C
Displays parameters regarding rotation
center when the head is dispensed.
Displays parameters regarding rotation
center measured per nozzle.
Dispensing head
Rotate center X[mm]/Y[mm]
XY coordinates of rotation center.
A
System
administration
NPM-W2 EJM7DE-MB-07O-00
Nozzle position
Offset of the selected nozzle is displayed
in .
7-3-6
Machine
parame-
ter
B
Placement head
You can check the X/Y/θ element offset values (calibration result) per head θ rotation angle.
BA
A
Dispensing head
A
B
C
C
A
Operating procedure
7-3-6
Offset per head angle
X[mm]/Y[mm]/ θ[°]
Offset values of X/Y coordinates and θ.
Nozzle position
Offset of the selected nozzle is
displayed in .
Component selection
Offset check per head
angle
B
Offset per head angle
X[mm]/Y[mm]/ θ[°]
Offset values of X/Y coordinates and θ.
B
A
NPM-W2 EJM7DE-MB-07O-00
7-3-7
Checking the nozzle
changer height
You can check the nozzle changer height offset (calibration result).
Machine
parame-
ter
Operating procedure
7-3-7
System
administration
A
C
B
B
C
Nozzle changer height Z[mm]
Height direction offset of the nozzle
changer.
Coordinates of A/B points
X[mm]/Y[mm]
A
Display switch
Switches parameter display of the
nozzle changer for placement (Mount) or
the nozzle changer for support pins
(Support)
