NPM-W 2 EJM7DE-MB-07 O-00 Checking light luminosity A A Light type Color Descriptio n Transpar- ency Red Transparen cy lighting ・ Luminosity offset value ・ Luminosity gain value Reflection Brown Reflection lighting ・ Lum…

100%1 / 714
NPM-W2 EJM7DE-MB-07O-00
Machine
parame-
ter
Multi-recognition
camera check 1
設備に設置されているフィーダーのメモリー情報を表示します。
Checking camera magnification/offset
You can check the offset values (calibration result) of the Magnification/Light luminosity/Lamp value of the
multi-recognition recognition camera.
C
A
B
Operating procedure
7-3-17
Mgfc.
Magnification of the multi-recognition
camera set to the recognition device.
●Used in calculating component
recognition.
Offset
Offset of position that moves when
recognizing with the recognition camera.
Choose a nozzle corresponding to the
values that you want to display in [Offset].
(Only for the 8-nozzle head)
7-3-17-1
B
C
A
D
Offset of tilt of the multi-recognition
camera against the X-axis.
D
Sensor angle [ °]
NPM-W2 EJM7DE-MB-07O-00
Checking light luminosity
A
A
Light type Color Description
Transpar-
ency
Red
Transparency lighting
・Luminosity offset value
・Luminosity gain value
Reflection Brown
Reflection lighting
・Luminosity offset value
・Luminosity gain value
●The reflection evaluation
value is used to evaluate
deterioration of light
luminosity
Side Peach
Side lighting
・Luminosity offset value
・Luminosity gain value
B
D
C
D
B
D
C
Enlarged drawing of
E
E
B
C
Light luminosity offset and
luminosity gain value
Side lighting
Transparency lighting
Reflection lighting
7-3-17-2
System
administration
NPM-W2 EJM7DE-MB-07O-00
Machine
parame-
ter
Multi-recognition
camera check 2
A
Light mode
●Transparency: Transparency mode
●1: Reflection 1 mode
●2: Reflection 2 mode
●BGA: Reflection BGA mode
A
B C D
設備に設置されているフィーダーのメモリー情報を表示します。
Multi-recognition camera lamp value
B
Light
C
Standard value
Lamp standard value for each light
mode.
D
Offset
Lamp offset for each light mode.
Display Color Type
Transparency Red
Transparency
lighting
Reflection Brown
Reflection
lighting
Side Peach Side lighting
Enlarged drawing of
H
F EG
EF G
H
E
G
F
Side lighting
Transparency lighting
Reflection lighting
Operating procedure
7-3-17
7-3-17-3
