9 At a Glance
NPM-W2 EJM7DJ-MB-08O-00
System
function
details
Precautions on
operation 2
Operating procedure
8-2-3
8-2-3-3
Case Solution
If component is not placed on land
without APC correction
Check placement coordinate and parameters.
Specified component has a certain
amount of misalignment
Check if coordinates and relative positions of the placement
coordinate data and the gerber data for mask solder printing are
correct, and also check that the data is matched to the data actually
used for production.
●When both data sets are merged by DGS, the relative relation
between the placement coordinate and solder position is recorded,
and the correction position is calculated based on that data.
If a flat offset is applied to all PCBs
Check if the PCB recognition coordinate is correct. Also, check that
the relative position is correctly matched (the center coordinate of
two solder centers for a chip component should be matched to the
placement coordinate of the component) when the placement
coordinate data and the gerber data are merged by DGS.
Margining placement coordinate data and gerber data
Mask hole data
Relative
position OK
Relative
position NG
Mask hole center
Component
placement coordinate
Component outer
data
If a placement position is misaligned before reflow
1)
1) The design value shall be used for the placement coordinate data and PCB recognition coordinate data.
After data creation, if the data of the placement coordinate is edited based on the actual component, APC
correction may not perform properly.
The production method by using the APC system corrects the data to produce conforming PCBs with
considering influence on solder misalignment caused by PCB and mask deformation, and other factors.
Because component variation is correctly measured, the design value must be used for the placement
coordinate data and the PCB recognition coordinate data.
9 At a Glance
NPM-W2 EJM7DE-MB-09O-00
Specifi-
cation
Machine specifications/
Basic performance 1
9-1-1-1
Operating procedure
9-1-1
Machine specifications
Item
Specification
Control system Microcomputer system
External memory
The data is managed by LNB
3)
Approximately 1MB is required for a piece of data
Program data
1）
Number of placement points: Max. 10 000 points /machine
(Placement coordinates, recognition mark coordinates, bad
mark coordinates and PCB height measurement points are
included.)
* In the case of production in dual lane mode, it is the total
number of placement points in the front and rear lanes. In
the case where the number of placement points is more
than 10 000points/line, please consult with us separately.
Also, about the line mixed with the CM/DT series, please
consult with us separately.
Power
source
Machine body
Normal service power source: Three-phase AC 200 / 220
±10 V, Three-phase AC 380 / 400 / 420 / 480 ±20 V
Frequency: 50 /60 Hz
Peak current value during operation: 40 A (rated voltage AC
200 V)
Rated
capacity
Machine body 2.8 kVA
Supply air pressure 0.5 to 0.8 MPa (working air pressure: 0.500 to 0.505 MPa)
Supply air volume 200 L / min (A.N.R.)
Outside
dimensions
Main body only
W 1 280 D 2 465 H 1 444 mm
(The signal tower and the touchscreen are not included)
With a supply unit
■When a feeder cart
4)
is connected
W 1 280 D 2 465 H 1 444 mm
(The signal tower and the touchscreen are not included)
■When a tray feeder
4)
is connected
W 1 280 D 2 570 H 1 444 mm
Mass
2)
Main body
2 470 kg per unit (Mass of 190 kg per unit of a standard
configuration feeder cart
4)
is not included)
Feeder cart
4)
190 kg per unit
Single tray feeder
4)
200 kg per unit
Twin tray feeder
4)
360 kg per unit
Standard configuration
2 850 kg (one main unit and two feeder carts
4)
)
Environmental condition
Temperature: 10 to 35C
Humidity: 25 to 75% RH (no condensation)
Altitude 1 000 m or less above sea level
Noise < 70 dB (A)
1)
This machine can modify only some data. The data is created by NPM-DGS.
NPM-DGS is software creating production data for NPM (not included in this product)
2)
Mass of the main body excluding the optional units.
3)
LNB (Line network box) manages the production data shared in the line.
4)
Options
