NPM-W2 EJM7DE-MB-09O-00
Specifi-
cation
Machine specifications/
Basic performance 6
Operating procedure
9-1-1
9-1-1-11
Recognition unit configuration 4
■Part thickness measurement function (Multi-recognition camera: [Type 2])
Improves placement quality through measurement of part thickness.
Item Description
Applicable
component
Each time 03015R
*1)
to Mini Tr / Di
Minimum part thickness: 0.1 mm
*To detect the pickup of a component being in a standing or slanted position, the difference
between any two of the following --- the thickness, width and length of the component ---
needs to be at least 50 μm.
Function
Part thickness
measurement
function
Each time
Part thickness is measured each time, which is
reflected in placement height. In addition, you can
simultaneously check the pickup of micro parts being
in a standing or slanted position and the reversing
pickup of Tr / Di.
Part teaching
You can make thickness measurement and chip data
entry on a per-part basis.
Nozzle top check
function
Checks the height of the nozzles for abnormalities.
*2)
Eject detection
function
If an error such as a recognition error has occurred, it checks the top of
the nozzles for any extraneous / foreign matter after ejecting parts.
・ This is not applicable to the measurement of nozzles with a pad or nozzles (e.g., 205A) the top of which is
dished.
・ Purchase on a per-table (front / rear) basis.
*1) When selecting “03015 placement support (option)”.
*2) Breaks, sliding failures in nozzle holders
NPM-W2 EJM7DE-MB-09O-00
9-1-1-12
At
a glance
2D inspection head specifications (option)
Item Specification
Mass
*1)
Inspection box
70 kg (per unit)
This section describes the specifications of machines equipped with the 2D inspection head.
For specifications common to machines with the placement head only (→P.9-1-1
-1 to P.9-1-1-3)
*1) Mass of the main body excluding the optional units
■Machine specifications
■Basic performance
*2) It varies depending on the inspection conditions
Item 2D inspection head (A) 2D inspection head (B)
Resolution 18 μm 9 μm
Field of view 44.4 x 37.2 mm 21.1 x 17.6 mm
Inspection
time
*2)
Solder 0.35 s / view
Component 0.5 s / view
Target
components
Solder
Chip component: 0.1 x 0.15 mm or
over
Package component: φ 0.15 mm or
over
Chip component: 0.08 x 0.12 mm or over
Package component: φ 0.12 mm or
over
Component
Square chip (0603 or over), SOP, QFP
(0.4 mm pitch or over), CSP, BGA,
aluminum electrolytic capacitor,
volume, trimmer, coil, connector,
resistor network, transistor, diode,
inductor, tantalum capacitor, MELF
Square chip (0402 or over), SOP, QFP
(0.3 mm pitch or over), CSP, BGA,
aluminum electrolytic capacitor, volume,
trimmer, coil, connector, resistor network,
transistor, diode, inductor, tantalum
capacitor, MELF
Inspection
item
Solder Oozing, blur, misalignment, shape defect, bridge
Component Component existence, misalignment, flip-over, polarity, foreign matter inspection
Inspection position
accuracy
Cpk≧1)
± 20 μm ± 10 μm
Inspection
point
Solder
Maximum 30 000 point per machine (component point: Maximum 10 000 points
per machine)
Component Maximum 10 000 points per machine
NPM-W2 EJM7DE-MB-09O-00
9-1-1-13
Specifi-
cation
Machine specifications/
Basic performance 7
Operating procedure
9-1-1
Dispensing head specification (option)
Item Description
Dispensing direction
(angle)
-180° to 180° (in increments of 0.01°)
●Fixed at 0° for dummy
Dispensing range Conforming to the placement head
*1)
PCB flow direction Conforming to the placement head
Available nozzle count Up to 2 types
Dispensing tact time 0.16 s/dot (under optimum conditions)
Dispensing position repeat
accuracy
±0.075 mm (Cpk≧1.0)
Drawing tact time 3.75 s / Part (at the optimum condition)
Drawing position accuracy
±0.1 mm (Cpk≧1.0)
Temperature adjustment Heater
Dispensing pressure Programmable with the electropneumatic regulator
PCB changing time Conforming to the placement head
Adhesive ADE850D (recommended)
*2)
, ADE820DX (recommended)
*2)
Applicable component 1608 chip to SOP,PLCC,QFP,Connector,BGA,CPS
Dummy dispensing unit Standard equipment
Nozzle type
*3)
1-point nozzle
*4)
, 2-point nozzle, 4-point nozzle
Remaining amount
detection
After the detection of empty, stop or warning at the timing of arbitrary
dispensing
Such as solder apply, silver paste apply, and corner adhesive apply need technical confirmation.
1
) The value may vary by the anti-dispensing-on-rail function.
2
) For another maker, please consult us.
3
) As for the dispensing nozzle, there may be some changes.
4
) 1-point nozzle has two types of nozzles (dot dispensing and drawing dispensing)
