1 Installation 1-3 Production Line To align your assembly line, first in stall the heaviest unit. Th en install peripheral u nits using th e first unit as a reference. Reference Loader Mounter Reflow Oven Conveyor Unload…

1 Installation

1-2

Installation of Mounter

Environmental Requirements

Install the mounter where the below conditions are met.

Do not do tasks, such as moving the machine or connecting the machine with the main switch ON to

prevent electric shock.

■ Ambient Temperature: 15 to 35 degrees C

■ Relative Humidity: 45 to 60 percent, non-condensing

■ Atmosphere: Dust and corrosive gas free

■ Floor: Floor must be flat and sturdy enough for freedom from vibration during

operation.

■ Power Requirements: 200 VAC +/- 10%, three phase, 50/60 Hz

* 208/220/230/240/380/400/415/440 VAC with optional power

transformer

Power consumption: 2 kW

Capacity: 5 kVA

Leakage current: 100mA or less

* Power and ground the machine independently of other machines which may be a

noise source, such as a compressor, welding machine, or reflow soldering machine

with magnetic contacts.

Warning

1 Installation

1-3

Production Line

To align your assembly line, first install the heaviest unit. Then install peripheral units using the first unit as

a reference.

Reference

Loader　　　　Mounter　　　　　Reflow Oven　　　Conveyor Unloader

To transfer the PCB (printed circuit board) smoothly, clearance between units are quite important. Be sure

that the clearance between units is approximately 5 mm as below figure shows. Adjust the height of the

downstream unit a little lower (0-0.5 mm) so that the PCB is transferred smoothly.

0 - 0.5mm

Approx. 5mm

DownstreamUpstream

側

1 Installation

1-4

Installing the Mounter

Do not touch terminals of electric components when the power is on to prevent electric shock and machine

damage.

Make sure to ground the mounter to prevent electric shock.

ACTION:

① Locate the mounter to the specified place.

② Adjust the conveyor height to 900 mm by rotating the adjust feet.

900+/-20mm

950+/-20mm(SMEMA)

③ Place a level on the conveyor and adjust the height so that the mounter is level lengthwise and

crosswise.

Warning
