2 Periodical Checks
2-1
2
Periodical Checks
2 Periodical Checks
2-2
Daily Checks
Visual Check
Check the followings before turning on the main switch and power switch of the mounter.
NOTE: Power source and air supply must be in the ON state.
ITEM DESCRIPTION
Temperature and Humidity
Make sure temperature is in the range of 15 to 35 deg. and humidity 45 to 60%
(non-condensing).
Room Environment
If air is dusty, check air filters.
If mounter surface rusts as a result of corrosive gas, check vents, reflow ovens,
and board cleaners.
Air Supply
Make sure air pressure of regulator is 0.49 MPa (5kg/cm
2
).
If drain cock contains water, drain it. (Adjusting temperature of dry air may be
required.)
If drain contains oil, investigate the cause.
Reject Tray (Front & Rear)
Make sure of the setting direction of the reject tray.
Make sure that the ends of the reject tray and the tape guide (on which station No.
sticker is placed) meet.
Make sure that the reject tray sits properly and is not lifted by electronic
components.
Conveyor
Make sure conveyor width of all the peripherals are the same.
Make sure no obstacles are on conveyor.
Head Moving Range
Make sure no obstacles are in head moving range, e.g. on the adjust plate.
Scan Camera
Check mirror for dirt and flaw. Clean if dirty.
Note: If dust settles or condensation occurs on the mirror, the reflectance drops,
causing illumination to need to be brighter. This may lead to a drop of recognition
rate. To avoid this, always keep the mirror clean.
)
”Camera” in 3 Mechanical Section.
Fixed Camera
Make sure no obstacles are on fixed camera.
ANC
Make sure no obstacles are around ANC tower.
Nozzle
Clean nozzles if dirty. Replace if deformed.
Feeder Bank
Clean front and rear feeder banks.
Make sure tape feeders are set on bank securely. If not, it may cause head
collision.
2 Periodical Checks
2-3
MX-40 (Optional)
Make sure no obstacles are on pallets.
MX-20 (Optional)
Make sure no obstacles are on pallets.
MX-ST2 (Optional)
Make sure no obstacles are on pallets.
Input/Output Terminal Assembly
Check connections of connectors and air hoses.
