MODEL TCM-3700-2 0109-001 202 㔚᳇ᓮㇱ ELECTRICAL SECTION Fig.11-5 ࠪࠤࡦࠬࡏ࠶ࠢࠬ Relay Sequence Box A 1 114 111 111 112 112 113 113 108 92 107 30 A C D E B B 24 25 25 26 86 82 83 83 29 28 27 9 2 8 7 3 32 15 18 19 20 15 18 91…
MODEL TCM-3700-2
0109-001
201
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
11-4
1 630 094 2897 BRACKET 1 739FB-01V-002
2 630 086 0245 UNIT,POWER 1 PSU4, PAA600F-24 739FB-01D-079
5 411 035 2707 SCR FLT 4X8 4 M4X8 FLT
6 630 085 4138 UNIT,POWER 1 PSU5, PAA-300F-24 739FB-01D-080
7 411 119 2104 WASHER V 4X9X0.8 4 FW4 F
8 411 008 1706 WASHER SPR 4 4 SW4 F
9 411 043 5004 SCR PAN 4X8 4 M4X8 PAN
30 630 049 1135 UNIT,POWER 1 PSU10, P15E-5-N 739FB-01D-108
32 411 119 1909 WASHER V 3X7X0.5 2 FW3 F
33 411 086 4408 WASHER SPR 3 2 SW3 F
34 411 042 0703 SCR PAN 3X8 2 M3X8 PAN
54 630 001 0220 WASHER 3 BW5
55 411 141 6705 WASHER SPR 5 3 SW5
56 630 000 7756 BOLT,HEX-SCT 3 M5X12
MODEL TCM-3700-2
0109-001
202
㔚᳇ᓮㇱ ELECTRICAL SECTION
Fig.11-5 ࠪࠤࡦࠬࡏ࠶ࠢࠬ Relay Sequence Box
A
1
114
111
111
112
112
113
113
108
92
107
30
A
C
D
E
B
B
24
25
25
26
86
82
83
83
29
28
27
9
2
8
7
3
32
15
18
19
20
15
18
91
19
94
20
95
96
93
14
14
14-1
10
11
12
13
49
115
F
15-1
18
19
20
F
G
82
84
68
78
77
60
59
58
57
67
66
64
63
72
70-2
70-1
86
81
85
.
73
71
75
17
C
D
18
19
20
.
79-3
79-1
79-2
76
65
62
70
74
.
50-1
50
.
101
124
123
122
121
125
101
105
106
104
103
102
16
18
19
20
53
60
53-1
.
51
51-1
.
6
5
4
9-2
9-1
31
43
34
40
46
37
46
49
41
44
48
47
39
38
47
48
33
45
42
39
36
35
37
38
E
126
127
128
132
130
131
G
TCM-3700-2
Fig.11-5
MODEL TCM-3700-2
0109-001
203
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
11-5
1 630 094 4518 BOX 1 739BD-01V-001
2 630 059 1774 PLATE 1 739BD-01V-005
3 630 000 4243 SOCKET 3 739BD-01D-043
4 411 119 1909 WASHER V 3X7X0.5 6 FW3 F
5 411 086 4408 WASHER SPR 3 6 SW3 F
6 411 041 8908 SCR PAN 3X6 6 M3X6 PAN
7 411 119 2104 WASHER V 4X9X0.8 1 FW4 F
8 411 008 1706 WASHER SPR 4 1 SW4 F
9 411 043 5004 SCR PAN 4X8 1 M4X8 PAN
9 -1 411 087 1109 WASHER IN TW 5 1
9 -2 411 114 7807 SCR PAN+SW+W 4X10 1
10 630 049 2422 BRACKET,WIRING 8 739BD-01D-002
11 411 119 2104 WASHER V 4X9X0.8 16 FW4 F
12 411 008 1706 WASHER SPR 4 16 SW4 F
13 411 042 3001 SCR PAN 4X10 16 M4X10 PAN
14 630 049 2439 RELAY 7 CR9, CR17, CR18, CR24, CR25,
CR26, CR28 739BD-01D-001
14 -1 630 085 7498 RELAY 1 CR1 739BD-01D-705
18 411 119 2104 WASHER V 4X9X0.8 11 FW4 F
19 411 008 1706 WASHER SPR 4 11 SW4 F
20 411 043 5004 SCR PAN 4X8 11 M4X8 PAN
24 630 049 2088 SOCKET 2 739BD-01D-012
25 630 000 1037 BRACKET,WIRING 2 739BD-01D-014
26 630 049 2491 TIMER 2 TMR1, TMR4 739BD-01D-008
27 630 045 4260 SOCKET 3 739BD-01D-010
28 630 000 1037 BRACKET,WIRING 3 739BD-01D-014
29 630 007 3881 TIMER 3 TMR5, TMR6, TMR7 739BD-01D-007
30 630 082 3912 TIMER 1 TMR2 739BD-01D-009
31 630 049 2071 SOCKET 1 739BD-01D-013
32 630 000 1020 BRACKET,WIRING 1 739BD-01D-015
33 630 076 9814 RELAY 1 CR2 739BD-01D-005
34 630 045 4260 SOCKET 1 739BD-01D-010
35 630 000 1020 BRACKET,WIRING 1 739BD-01D-015
36 630 049 2125 RELAY 1 CR3 739BD-01D-003
37 630 013 5862 SOCKET 4 739BD-01D-011
38 630 000 1020 BRACKET,WIRING 4 739BD-01D-015
39 630 076 9807 RELAY 4 CR4, CR5, CR11, CR40
739BD-01D-004
40 630 045 4260 SOCKET 4 739BD-01D-010
41 630 000 1020 BRACKET,WIRING 4 739BD-01D-015
42 630 049 2125 RELAY 4 CR15, CR16, CR19, CR20
739BD-01D-003
43 630 049 2071 SOCKET 2 739BD-01D-013
44 630 000 1020 BRACKET,WIRING 2 739BD-01D-015
45 630 076 9814 RELAY 2 CR21, CR22 739BD-01D-005
46 630 045 4260 SOCKET 2 739BD-01D-010
47 630 000 1020 BRACKET,WIRING 2 739BD-01D-015
48 630 049 2125 RELAY 2 CR30, CR46 739BD-01D-003
49 630 049 3672 BRACKET,WIRING 2 739BD-01D-020
50 630 070 4808 FUSE HOLDER 1 739BD-01D-717
